HLA Snow 5205W Series
Videos
Overview
| |
|
Features |
- 2 Year Warranty
- Removeable Upper Wing Tip
- 180° Rotation
- 35° Angle with Crossover Relief Valve Protection
- Floating End Plate Edge
- Lateral Float
- Nitrate Rods on Angle Cylinders
- Replaceable, Reversible Cutting Edge
- Rotary Actuators - PATENTED
- Skid Shoes
- Spring Trip Cutting Edge
- Tire Protection System - PATENTED
- Double Selector Valve
- Quick attach frame kits available for most makes. Call dealer for details.
|
|
Specifications |
| |
| Part # |
Approx. Weight (LBS.) |
Clearing Width Closed (in.) |
Clearing Width Open (in.) |
Overall Road Width (Angled) (in.) |
Snow Clearing Width (Angled) (in.) |
Mouldboard Height |
Max Operating Weight (lbs.) |
| SB5205W919 |
4,115 |
108 |
228 |
103 |
189 |
42" |
40,000 |
| SB5205W1020 |
4,245 |
120 |
240 |
113 |
199 |
42" |
40,000 |
| SB5205W1222 |
4,510 |
144 |
264 |
133 |
219 |
42" |
40,000 |
| SB5205W1424 |
4,800 |
168 |
288 |
153 |
239 |
42" |
40,000 |
| SB5205W1626 |
5,120 |
192 |
312 |
173 |
259 |
42" |
40,000 | |
| |
