ID # 13869588
HLA Snow 4205W Series
Videos
Overview
| |
|
Features |
- 2 Year Warranty
- Removeable Upper Wing Tip
- 180° Rotation
- 35° Angle with Crossover Relief Valve Protection
- Floating End Plate Edge
- Lateral Float
- Nitrate Rods on Angle Cylinders
- Replaceable, Reversible Cutting Edge
- Rotary Actuators - PATENTED
- Skid Shoes
- Spring Trip Cutting Edge
- Tire Protection System - PATENTED
- Double Selector Valve
- Quick attach frame kits available for most makes. Call dealer for details.
|
|
Specifications |
| |
| Part # |
Approx. Weight (LBS.) |
Clearing Width Closed (in.) |
Clearing Width Open (in.) |
Overall Road Width (Angled) (in.) |
Snow Clearing Width (Angled) (in.) |
Mouldboard Height |
Max Operating Weight (lbs.) |
|
SB4205W818 |
3,290 |
93.5 |
213.5 |
91 |
160 |
34" |
25,000 |
|
SB4205W919 |
3,435 |
108 |
228 |
102 |
171 |
34" |
25,000 |
|
SB4205W1020 |
3,550 |
120 |
240 |
112 |
181 |
34" |
25,000 |
|
SB4205W1222 |
3,745 |
144 |
264 |
132 |
201 |
34" |
25,000 |
|
SB4205W1424 |
4,035 |
168 |
288 |
152 |
221 |
34" |
25,000 | |
| |
