HLA Snow

  Back
ID # 13451276

HLA Snow 5206W Series

  • HLA Snow 5206W Series
  • HLA Snow 5206W Series
  • HLA Snow 5206W Series
  • HLA Snow 5206W Series
  • HLA Snow 5206W Series
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

  Features
  • 2 Year Warranty
  • 6' Wings
  • Removeable Upper Wing Tip
  • 180° Rotation
  • Crossover Relief Valve
  • Floating End Plate Edge
  • Lateral Float
  • Nitrate Rods on Angle Cylinders
  • Replaceable, Reversible Cutting Edge
  • Rotary Actuators - PATENTED
  • Skid Shoes
  • Spring Trip Cutting Edge
  • Tire Protection System - PATENTED

  Options
  • Rubber Cutting Edge
  • Spill Guard
  • Boron or Carbide Cutting Edges
  • Curb Runner
  • High Tensile Long Wear Skid Shoes
  • Floating Blade Hinge
Part # Clearing Width Closed (in.) Clearing Width Open (in.) Overall Road Width (Angled) (in.) Snow Clearing Width (Angled) (in.) Mouldboard Height (in.) Weight (lbs.) Max Operating Weight (lbs.)
SB5206W921 108 252 103 205 42 4,135 40,000
SB5206W1022 120 264 113 215 42 4,260 40,000
SB5206W1224 144 288 133 235 42 4,530 40,000
SB5206W1426 168 312 153 255 42 4,805 40,000
SB5206W1628 192 336 173 275 42 5,125 40,000



Specifications
Model
5206W Series
Category Name
Snow Removal Attachments
Year
2016
Sale Type
New
Manufacturer
HLA Snow
