ID # 13451275
HLA Snow 1000 Series
Overview
| |
|
Features |
- Lateral Float
- Mouldboard Profile
- Replaceable, Reversible Cutting Edge
- Adjustable Skid Shoes
- Spring Trip Mould Board
|
|
Specifications |
| |
| Part # |
Approx. Weight (LBS.) |
Length (in.) |
Overall Road Width (Angled) (in.) |
Snow Clearing Width (Angled) (in.) |
Mouldboard Height |
Max Operating Weight (LBS.) |
|
SB100042 |
350 |
42 |
39.5 |
35 |
20" |
3,000 |
|
SB100048 |
365 |
48 |
44.5 |
40 |
20" |
3,000 |
|
SB100054 |
375 |
54 |
50 |
45 |
20" |
3,000 |
|
SB100060 |
385 |
60 |
56 |
50 |
20" |
3,000 |
|
SB100066 |
400 |
66 |
59.5 |
55 |
20" |
3,000 |
|
SB100072 |
410 |
72 |
65.5 |
60 |
20" |
3,000 |
|
SB100078 |
420 |
78 |
69.5 |
65 |
20" |
3,000 |
|
SB100084 |
440 |
84 |
74.5 |
70 |
20" |
3,000 |
|
SB100090 |
450 |
90 |
79.5 |
75 |
20" |
3,000 |
|
SB100096 |
465 |
96 |
|
|
20" |
3,000 | |
| |
Specifications
Category Name
Snow Removal Attachments
