Overview
MAX OPERATING WEIGHT: 25000 lbs.
  Features:
180° Rotation 180° Rotation
Infinitely and independently adjustable, our wings are rugged enough to stay put and give you control of any situation.
Crossover Relief Valve Crossover Relief Valve
Provides protection against hidden obstacles by redirecting hydraulic pressure, swinging the blade around hazards.
Floating End Plate Edge Floating End Plate Edge
Floating end-plate edges follow surface contour for confident snow clearing.
Lateral Float Lateral Float
Allows blade to follow ground contours for better clearing performance.
Nitrate Rods on Angle Cylinders Nitrate Rods on Angle Cylinders
Nitrate rods on angle cylinders.
Replaceable, Reversible Cutting Edge Replaceable, Reversible Cutting Edge
Our cutting edges are designed to be easily replaceable and are reversible to give you twice the life.
Rotary Actuators - PATENTED Rotary Actuators - PATENTED
These rugged units come from the construction industry and deliver 38,700 in. lbs of torque to hold the wings in place.
Skid Shoes Skid Shoes
AR400 high tensile skid shoes for optimum performance and prolonged cutting edge life.
Spring Trip Cutting Edge Spring Trip Cutting Edge
Allows cutting edge to trip back if struck by hidden object limiting damage.
Tire Protection System - PATENTED Tire Protection System - PATENTED
Our Tire Protection System means that you get the most out of your Snow Wing while keeping the air in your tires. The system automatically protects from unintended damaging collisions between your front tires and end plates. The end plates are automatically rotated away from the tires so the operator can focus on clearing snow and worry less about damaging equipment.
SPECIFICATIONS
PART
APPROX.
WEIGHT
LBS.
CLEARING
WIDTH
CLOSED
CLEARING
WIDTH
OPEN
MOULD-
BOARD
HEIGHT (IN)
MAX
OPERATING
WEIGHT (LBS)
SB4206W820
3080
7' 9.5"
19' 9.5"
 34 25000
SB4206W921
3160
9
21
 34 25000
SB4206W1022
3230
10
22
 34 25000
SB4206W1224
3460
12
24
 34 25000
SB4206W1226
3640
14
26
 34 25000



Specifications
Model
4206W Series
Category Name
Equipment
Year
2015
Sale Type
New
Manufacturer
HLA Snow
