H&S

ID # 13613688

H&S HDNR Rear Unload

Call for Price
Overview



 REAR UNLOAD POWER BOX FEATURES:

  • Rear Unload Power Boxes are available in 18' and 20' models.
  • The heavy duty tailgate is constructed to stand up to the pounding of heavy loads. High pivot points assure crop clearance while unloading.
  • The H&S Power Box is hydraulically driven. Unload time is dependent on tractor R.P.M., hydraulic pressure, and G.P.M.

 HDNR REAR UNLOAD POWER BOX FEATURES:

  • HDNR Rear Unload Power Boxes are available in 18' or 20' models.
  • The Power Box utilizes a two-hose hydraulic system to run the main apron. The hydraulic hoses are easily stored in the holder at the front of the box.
  • The Power Box features a chain reduction system instead of a worm gearbox for better efficiency.
  • All HDNR Power Boxes feature Cross Z-iron that is welded to the side channels in-line with stakes for added strength.
 Specifications

       HDNR POWER BOX                   18'                   20'
INSIDE WIDTH 7'4" 7'4"
OVERALL LENGTH 19'6" 21'6"
OVERALL WIDTH 104" 104"
STANDARD BOX OVERALL HEIGHT 101" 101"
STANDARD BOX CAPACITY STUCK LEVEL 950 cu. ft. 1056 cu. ft
WEIGHT – STANDARD BOX 6650# 7110#
MAIN APRON CHAIN 667H PINTLE CHAIN IS STANDARD, T-ROD,667X OR 667XH PINTLE CHAIN ARE OPTIONAL
MAIN APRON DRIVE CHOICE OF HYDRAULIC DRIVE OR P.T.O. DRIVE
UNLOAD SPEED UNLOAD TIME IS DEPENDENT ON TRACTOR R.P.M., HYDRAULIC PRESSURE AND G.P.M.
REAR ENDGATE AUTOMATIC LOCK AND UNLOCK
ROOF OPTIONAL OPTIONAL
REAR GATE DELAY OPTIONAL OPTIONAL
H&S POWER BOX      18'      20'
CAPACITY W/ROOF 994 FT 1106 FT
INSIDE WIDTH 7'4" 7'4"
OVERALL LENGTH 19'6" 21'6"
OVERALL WIDTH 104" 104"
OVERALL HEIGHT 118" 118"
WEIGHT 3650# 4050#





Specifications
Model
HDNR Rear Unload
Category Name
Agriculture
Year
2017
Sale Type
New
Manufacturer
H&S
