SPML9 | SPMLW9

Only from Grégoire-Besson:

• In or out of furrow labour.
• Offset by compass.
• Wheel diameter 1220 mm.
• Single arm wheel mounting :
  • easy access to wheel.
• Overall tractor width: up to 3.50m (out of furrow).
• Smaller distance between tyres:
  • Minimum : 1.40m.

Reversal by rack and pinion system

Articulated front end

• Turning angle: 110°.
• Maneuvrability and smaller headlands
• Hydraulic control of load transfer (option, Gregoire-Besson patent).

Compact "Z" Beam

• Optimal wheel placement.
• In the field it is further back permitting better load distribution and no overhang
• During transportation and pivoting the centre of gravity is lowered bringing better stability, significant load reduction on linkage arms.

Large wheel

• Larger diameter eases going over obstacles.
• The greater width offers more load bearing surface and better stability.
• The lugged profiles help control the plough in all conditions.
• Supension by nitrogen sphere  (option on SP9).
• The wheel bearing is also better protected from mud and dust.

Configuration adapted to your needs

• Scalability with up to 2 extra plough bodies.
• A  Grégoire-Besson exclusive feature an  additional body is mounted on the front beam to optimize the load transfer regardless of the number of bodies.

A full and up to date range

• Adjustable working width: multiposition shoes or hydraulic adjustment.
• Coulter (option).
• Centralised hydraulic function selector (standard on W9).
