Tuned Manifold

Each Yield-Pro® air manifold contains orifices to deliver the same volume of air to every row. This detail helps ensure consistent seed rates throughout.

SPRING-LOADED CONTACT GROUND DRIVE

Allows the drive wheel to absorb undulations in the field to maintain consistent drive speed.

SENSORS

Internal meter pressure is constantly measured and adjusted automatically to deliver unmatched seed singulation.

6" HYDRAULIC FAN

Provides air pressure to each Air-Pro(R) Meter.

Seed Capacity

The 2.4 bu./ft. seed box combines the large capacity of a grain drill with the accuracy of the 25 Series planter row unit. A V-bottom design ensures that all the seed in the seed box will empty.

Choose A Press Wheel

Choose (from left) cast for sticky Delta soils; wedge to pinch the seed trench together while providing a wide footprint; 1"x12" double-V for all-around performance; or spider wheels with drag chains that aggressively close the seed trench.

Available Row Spacings

Multiple row spacings are available to match a variety of needs, including 9.5" single- or 30", 36", 38", and 40" twin-row configurations.

Air-Pro® Meter

This simple, positive air pressure meter offers the highest level of singulation on the market today, and achieves uniform spacing by “dead-dropping” seed into the patented Clear-Shot® seed tube.

25 Series Row Unit

The 25 Series row unit utilizes ductile cast parallel arms for long-term row unit stability. 15", 4mm blades turning on 205 triple-lip seal bearings ensure long life and accurate seed depth. Blades are offset ½" to slice residue and form a perfect seed trench.
