Simplicity of Operation

Setting planting rates is fast and simple with a 4-speed sprocket transmission and easy-to-adjust seed-rate handle.

LOCKOUT HUBS

Quickly disengage all chains and sprockets for reduced wear during transport.

Hydraulic Down Pressure

A single hydraulic cylinder lifts openers out of the way for transport and end-row turns (inset). The same cylinder also applies down pressure to the 5-position down-pressure adjustment stop. This setting allows the operator to quickly change the amount of down pressure on openers.

T-Handle Depth Control

T-handle offers 18 different positions for accurate depth control.

Press Wheel Options

Single press wheels include a 3"x13" double rib* press wheel; a 3"x13" center rib press wheel; a 2"x13" smooth press wheel; or a 3"x14" peak press wheel for arid areas. A 1"x12" double-V press wheel is also offered for 7½" and 10" spacings.

End Wheel Drive

Large end wheels provide excellent ground drive to the seed meters. Lockout hubs save drive components from wear.

3.2 Bushel-Per-Foot Seed Box

Largest seed box in its class means more time seeding and fewer stops to fill.

00 Series Opener

Great Plains 00 Series openers are designed for min-till fluted feed drills. The 00 opener features 13.5", 4mm blades mounted on 205 triple-lip sealed bearings. The 00 opener has a ¼" lead opener blade. Hydraulic down pressure is transmitted from the toolbar to the heavy-duty down-pressure spring to apply ample penetration and depth control. The full-length seed tube guides seed all the way to the bottom of the seed trench to ensure excellent seed placement.
