VERSATILE BOX COMBINATIONS

Seed up to three different seeds at the same time (main seedbox, Native Grass, Small Seeds).

GROUND DRIVE

Eight- position positive ground drive also works as the front depth gauging wheel.

3-POINT MOUNTED

Category II 3-point mounting setup.

T-Handle Opener Depth Adjustment

Provides 18 different positions for accurate depth control.

Press Wheel Options

Choices include, from left, 3"x13" double rib*; 3"x13" center rib; 2"x13" smooth; 1"x12" double-V; or double wedge-style press wheels that create a pinching action to close the seed trench.

Lead Coulter Options

Choose between a 5/16" fluted coulter blade (left) that penetrates easily for minimum tillage or a 5/8" Turbo coulter blade (right) that is more aggressive and prepares a mini seedbed ahead of the opener. Preloaded springs offer 450 lbs. of down pressure per row on the leading coulter.

Large Box Capacity

With a 2 bu./ft. capacity, a larger seed box reduces downtime and covers more acres per fill.

Fluted Seed Cups

With powdered metal flutes, these 1¾" seed cups deliver outstanding accuracy.

4-Speed Gearbox

Changing seed rates is quick and effortless with these permanently lubricated, sealed gearboxes.

06 Series Opener

The 06 Series row unit utilizes the “Fluff and Plant” no-till system with an integrally-mounted coulter to cut residue and prepare a mini seedbed for the trailing double-disc opener. The opener discs are 13.5" in diameter and 4mm thick with 205 triple-lip sealed bearings, and ¼" opener disc lead. Our unique full-length seed tube design and trailing flap control the seed all the way to the bottom of the seed trench where the seed stays in place.
