Wheel Track Removal

CTA implement models have an extra opener mounting position to lower the openers that are directly behind tractor tire tracks, ensuring proper seed placement and depth control.

Uniform Seed Distribution

A single fan supplies air to a divided manifold where the star-wheel meters drop the seed into the airflow of each tower. The towers use a transition cone to uniformly divide the seed to individual rows. Full-length seed tubes complete the process, delivering seed to the bottom of the trench.

Press Wheel Options

Single press wheel options include 3"x13" double* or center rib, 4"x12" V-groove**, 2"x13" smooth, or 3"x14" peak**. Double press wheels include 1"x12" smooth or wedge-style**.

Large Capacity on Dual-Bin Carts

A split-bin design allows easy access when filling either the two 110 bu. steel hoppers or two 175 bu. poly hoppers. Fill one hopper with fertilizer and one with seed, or fill both with seed or both with fertilizer. An auger system will also empty the bins.

Integral Configuration

The integrated cart-to-implement offers exceptional maneuverability when backing into a storage shed or the corners of a field.

Distribution Towers

Dimpled distribution towers and transition cone divide seed equally for excellent seed distribution across the entire drill.

Constant Hydraulic Down Pressure

Active hydraulics optimize seed placement by keeping openers in uniform contact with soil. Down pressure is applied independently at both ends of the subframe, maximizing opener ground-hugging capabilities in uneven conditions.

Active Weight Transfer

Active hydraulic weight transfer maintains even, consistent penetration across the entire width of the implement.

00 or 00HD Openers

The Great Plains CTA-4000 and CTA-4500 Air Drills are offered with either 00 or 00HD (shown) offset opener blades. 00 Series openers are 13½" in diameter and offset ¼" to aid in penetration. 00HD Series openers feature 15" blades and a full ½" offset to be more aggressive in tough conditions. They also feature heavy 4mm blades with a special “no-till” bevel to ensure maximum residue cutting and consistent penetration.
