Great Plains Ultra-Chisel™

  • Great Plains Ultra Chisel™
  • Great Plains Ultra Chisel™
  • Great Plains Ultra Chisel™
  • Great Plains Ultra Chisel™
  • Great Plains Ultra Chisel™
  • Great Plains Ultra Chisel™
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Hqdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Model Numbers

6321UC, 6324UC, 6327UC, 6329UC, 6330UC, 6333UC, 6539UC, 6541UC, 6543UC, 6545UC

All models available with 9" or 12" shank spacing.
Product Description
Ultra-Durable Tillage

Offered in working widths from 21' to 45', these heavy-duty chisel plows feature 900 lb. trip force for consistent tillage in the 8" depth range. The Ultra-Chisel’s optional rocking bolster system on the center rockshaft ensures even, steady depth control in undulating field conditions, offering unmatched depth uniformity when compared to other large tillage tools in today’s chisel marketplace.

The Ultra-Chisel does a complete job of tilling the entire 6" to 8" soil profile, often eliminating the need for a follow-up pass prior to the seedbed preparation pass. To create a vertically-tilled soil environment, Ultra-Chisel can be equipped with 7" wing points, which are specially designed to create total fracture across the entire profile rather than just rip slots in the soil. Alternatively, large 12" or 16" sweeps can be used for deep tillage and weed control. Optional rear-leveling attachments include a five-bar high-residue spike harrow, a three-bar heavy coil tine, or a three-bar heavy coil tine with a finishing reel.
 Product Features

Great Plains Walking TandemWALKING TANDEMS

Cutting-edge materials and state-of-the-art seals allow this pivot to be maintenance free.

Great Plains Walking TandemSingle-Point Depth Control

Adjust the depth across the entire width of the machine in one convenient place.

Great Plains Walking TandemROCKING BOLSTER

A center-compensating rocking bolster on 5-section models keeps all four sets of center-frame walking tandems firmly on the ground in uneven terrain.

Great Plains Walking TandemHEAVY-DUTY SPRING-TINE HARROW WITH OPTIONAL REEL

With three-position adjustable angling, these longer, heavy-duty spring tines increase trash flow while filling in ruts and leveling fields in one pass.

Great Plains Walking TandemHeavy-Duty Chisel Shank

The Ultra-Chisel’s spring-loaded shanks have 900 lbs. of trip force and 30" of underframe clearance.

Great Plains Walking TandemFLOATING HITCH

The floating hitch lets the tractor and the machine's frame pivot independently so all wheels remain on the ground. This enables all transport tires to carry the whole weight of the machine and ensures uniform, even tillage.

Great Plains Walking TandemChoose Your Chisel Point

Choices include 2" straight points, 7" winged points, 3" or 4" twisted points, or 12" or 16" hard-faced sweeps. Availability is based on shank spacing.
 Specifications

Ultra-Chisel­­­™: 3-Section, 9" Shank Spacing

MODELS

6321UC

 6324UC 6327UC 6329UC 6330UC 6333UC

NO. OF SHANKS

(9" SHANK SPACING)

 29 33 37 39 41 45

WORKING WIDTH

21' 9"

24' 9"

 27' 9"

29' 9"

 30' 9"

33' 9"
TRANSPORT WIDTH 13' 8" 13' 8" 13' 8" 13' 8" 16' 8" 16' 8"

TRANSPORT HEIGHT

 10' 10"

12' 4"

13' 10"

14' 7"

13' 10"

15' 4"
ENGINE H.P. REQ

190+

210+

240+

250+

270+

290+

Ultra-Chisel™: 3-Section, 12" Shank Spacing



MODELS

6321UC

 6324UC 6327UC 6329UC 6330UC 6333UC

NO. OF SHANKS

(12" SHANK SPACING)

 22 24 28 30 32 34

WORKING WIDTH

21' 9"

23' 9"

 27' 9"

29' 9"

 30' 9"

32' 9"
TRANSPORT WIDTH 13' 8" 13' 8" 13' 8" 13' 8" 16' 8" 16' 8"

TRANSPORT HEIGHT

 10' 10"

11' 10"

13' 10"

14' 10"

13' 10"

14' 10"
PTO H.P. REQ

190-220

200-250

240-290

250-325

250-350

325-450



Ultra-Chisel­­­™: 5-Section, 9" Shank Spacing



MODELS

6539UC

 6541UC 6543UC 6545UC

NO. OF SHANKS

(9" SHANK SPACING)

 51 53 57 61

WORKING WIDTH

38' 3"

39' 9"

 42' 9"

45' 9"
TRANSPORT WIDTH 16' 1" 16' 1" 16' 1" 16' 1"

TRANSPORT HEIGHT

 13' 3"

13' 3"

13' 8"

13' 8"
ENGINE H.P. REQ

330+

340+

370+

400+



Ultra-Chisel™: 5-Section, 12" Shank Spacing

MODELS

6539UC

 6541UC 6543UC 6545UC

NO. OF SHANKS

(12" SHANK SPACING)

 39 41 43 45

WORKING WIDTH

39'

41'

 43'

45'
TRANSPORT WIDTH 16' 1" 16' 1" 16' 1" 16' 1"

TRANSPORT HEIGHT

 13' 5"

13' 5"

13' 10"

13' 10"
PTO H.P. REQ

330-400

330-420

345-440

360-460





Specifications
Model
Ultra-Chisel™
Category Name
Agriculture
Year
2020
Sale Type
New
Manufacturer
Great Plains
