ID # 15521523

Great Plains Turbo-Seeder™ Attachment

  • Great Plains Turbo Seeder™ Attachment
  • Great Plains Turbo Seeder™ Attachment
  • Great Plains Turbo Seeder™ Attachment
  • Great Plains Turbo Seeder™ Attachment
  • Great Plains Turbo Seeder™ Attachment
  • Video Button Maxresdefault
  • Video Button Hqdefault
  • Video Button Hqdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Model Numbers

24 cu/ft model is currently available for the 12', 15', and 18' Turbo-Max, Turbo-Till*, and Turbo-Chopper* models.

45 cu/ft model is currently available for the 24' and 30' Turbo-Max, Turbo-Till*, and Turbo-Chopper* models, as well as the 35' and 40' Turbo-Max models.
*Effective October 1, 2017, Turbo-Till and Turbo-Chopper models will no longer be manufactured
Product Description
Cover Crop Seeder

Reap the benefits of both cover crops and true vertical tillage with the Turbo-Seeder™ attachment from Great Plains! Now available in two different sizes, this seeder can be installed on select Turbo-Max®, Turbo-Till®, or Turbo-Chopper® models.

Turbo-Seeder offers a cost-effective, highly productive method for seeding cover crops with a vertical tillage tool. With Turbo-Seeder, you can simultaneously till your soil, size residue, and plant cover crops in one pass, while also reducing labor, fuel, and the maintenance costs of conventional planters.

Produced in partnership with Gandy of Owatonna, Minnesota, Turbo-Seeder is a complete, easy-to-install attachment that will come with either a 24 or 45 cu. ft. hopper. The meter shaft is powered by a 12-volt, 25-amp motor, and an 8-gpm hydraulically-driven fan delivers seed to the diffusers. Four seed rate meter wheels are included to match your seed rate requirements. Turbo-Seeder can place high rates of cover crops and small grains, such as oats, wheat, rice, and rye grass. The Turbo-Seeder kit also includes a ladder and walkboard for easy access to the hopper.

Protect your soil, and the environment, with Turbo-Seeder from Great Plains.

 Product Features

Great Plains Walking TandemZero-Max® Meter Drive

12-volt, 25-amp meter offers infinite rate adjustments.

Great Plains Walking TandemLadder and Walkboard

For easy access to the seed hopper without climbing over the machine.

Great Plains Walking TandemHose Kit

The Turbo-Seeder has 12 or 16 diffusers and 1-1/4" diameter hose for unrestricted air and seed flow.

Great Plains Walking TandemElectric Solenoids

Provide section control on each half of the machine to avoid wasting seed on double-seeding.

Great Plains Walking TandemEasy-Fill Hopper

Slide-away cover speeds and simplifies fills, and the large hoppers are ideal for even large-acreage operations.

Great Plains Walking TandemDiffuser Plate

Distributes the seed laterally and downward in even, 30" bands.

Great Plains Walking Tandem8-gpm Hydraulically-Driven Fan

Achieves even seed distribution across the entire machine. Delivers seed to individual diffuser plates.
 Specifications

MODEL INFO



COVER CROP ATTACHMENT


MODELS 24 CU/FT TURBO-SEEDER 45 CU/FT TURBO-SEEDER

HOPPER SIZE (cu. ft.)

24

 45

METRIC CAPACITY (cu. m.)

.65

 1.2

BUSHEL CAPACITY (approx.)

19.2

 36

CHEMICAL CAPACITY (lbs.)

960

 1,800

OUTLET OPTIONS (max.)

16

 24

MAXIMUM BROADCAST WIDTH AT 30" DEFLECTOR SPACING (ft.)

40

 60

MAXIMUM BROADCAST WIDTH AT .76m DEFLECTOR SPACING (m.)

12

 18

SHAFT OPTIONS

Single

 Split

12-VOLT ELECTRIC DRIVE - NON-SPEED COMPENSATING

Standard

 Standard

ZERO-MAX CONTROLLER

Standard

 Standard



Specifications
Model
Turbo-Seeder™ Attachment
Category Name
Agriculture
Year
2020
Sale Type
New
Manufacturer
Great Plains
