Great Plains LC25-0836 Lister Cultivator

  • Great Plains LC25 0836 Lister Cultivator
  • Great Plains LC25 0836 Lister Cultivator
  • Great Plains LC25 0836 Lister Cultivator
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Dual-Purpose Toolbar

Lister Cultivator

The Lister Cultivator is built in the spirit of other Great Plains equipment with a focus on innovation, functionality, and toughness.

The LC40 Lister Cultivator combines a stack-fold toolbar with versatile parallel linkage row units. The new LC25 utilizes the same row units in a narrower, non-folding frame. The parallel linkage and depth band coulters allow for precise depth gauging on individual rows. The row units can be configured to 30", 36", 38", and 40" row spacings. Users can configure it as a lister or turn it into a row-crop cultivator with rear sweeps.

Additional benefits include:
• Thicker mainframe walls for long-term durability
• Laser-cut depth gauges for precise row unit depth gauging
• Wider depth-gauging coulter mountings for added strength and stability
• Triple-bar center frame support for greater reliability

Like all Great Plains equipment, the LC40 and LC25 are designed to provide precise, reliable performance in building, maintaining, and/or cultivating bedded ground.
 Product Features
Multiple Row Unit Configurations
Row Units

Choose from short or long lister bodies with barring off discs as an option, or short or long cultivator sweeps with a choice of depth coulters or depth tires with ability to add a side shield to either cultivator configuration.
Exclusive Maintenance-Free Bearings
Great Plains Exclusive Maintenance-Free Bearings

Great Plains uses the exclusive PEER® TILLXTREME® Maintenance-Free Pillow-Block Bearings in its gangs, as well as smaller TILLXTREME Maintenance-Free Bearings in its rolling attachments.
Depth Coulter
Depth Wheel

An open gauge wheel yoke design places the bracing where it is needed for strength but out of the way for trash flow. A steel depth gauge and positive lock ensure the depth stays where you put it.
3-Point Hitch
3-Point Hitch

The 3-point lift frame extends the length of the center section, creating a fully trussed mainframe. The Lister Cultivator is available in category 3N, 3, 4N, and 4 configurations.





Specifications
Model
LC25-0836 Lister Cultivator
Category Name
Agriculture
Year
2015
Sale Type
New
Manufacturer
Great Plains
ROW SPACING
36''
TYPE
3-Point Mounted
ROW COUNT
8
NO OF ROW UNITS
9
WEIGHT (approx Lbs)
6,000+
PTO H P REQ (min)
170+
TILLAGE WIDTH
27' 11''
TRANSPORT WIDTH
27' 11''
TRANSPORT HEIGHT
6' 5''
