Heavy-duty Deck

Vigilant Operator Presence System™

• Standard, low profile operator protection structure (OPS) with an adjustable seatbelt
• Dampened steering levers that return to neutral from forward and reverse
• Interlock switches that shut down the engine when the operator leaves the seat while PTO is engaged or levers are in drive position

B&S Commercial Turf Engine

• 724 cc (44.2 cu. in.) Commercial Turf, V-Twin, OHV engine
• Heavy-duty components enhance power and reliability
• Five-step, Integrated Cyclonic Air Management System for cleaner performance
• Extended maintenance intervals
• Three-year limited commercial engine manufacturer warranty (see dealer for details)

Design-Matched Transmission

• Design-matched, fully hydraulic Parker HT Series integrated pump-and-wheel-motor transmissions with in-line cooling fans and fine-particle filtration
• No power-robbing gearbox or other wear parts for longer service life
• Provides best-in-class transmission fluid change interval with no break-in period, reducing costs and maintenance time

Shock Impact Reduction System™(SIRS™)

Warranty

• Commercial Use: 2-year or 500-hour (whichever comes first); limited warranty covering parts and labor.
• Residential Use: 4-year or 500-hour (whichever comes first); limited warranty covering parts and labor.

Ultimate Operator Station

ComfortZone™ seat eliminates jostles and jolts with coil-spring suspension and a fully padded, high-back seat, padded armrests and variable density foam cushion. Iso-mounting smooths the ride, erases fatigue and keeps the operator comfortably in control at faster mowing speeds

Operational controls including throttle, choke and angled View-Eze™ console and adjustable cup holder are well positioned for visibility and ease of reach

One- or two-handed operation with ComfortReach™ adjustable Hydra-Smooth™ dual levers that automatically return to neutral from either forward or reverse position.

QuikAjust Drop Pin Height Adjustment

Raise and lower the deck easily with foot pedal and drop pin for precision cutting heights between 1.0 and 5.0 inches.

Reduced Maintenance

- Only two Access-Eze™ lubrication points cut maintenance time up to 95%

- Self-tensioning belts minimize cost and labor on routine maintenance

Rugged Construction

- Robotically-welded steel construction for long-lasting durability

- Centered-bearing design provides greater load-bearing capacity to handle the weight of operator, fuel and high-capacity collector with reserve strength for curb shocks and weight shifts

- Tough-as-nails powder-coated finish is fusion-bonded for chip and rust resistance
