• Height to Hinge Pin - Fully Raised (mm): 96" (2438)
• Rated Operating Capacity (kg): 850 lbs. (386)
• Net Power (kW): 24 hp (17.9)

The 1640E Skid Loader was designed with quality in mind. There are few tasks this loader cannot handle.

• Power-view® lift arm provides strength, durability and excellent view of the tires and sides of the loader
• Universal-style quick-attach system makes attachment changes quick and easy
• Thick steel plating and heavy-duty pins and bushing strengthen the loader for extreme-duty work.
• SAHR (spring-applied, hydraulic release) brake system responds quickly, holding the loader whenever the operator leaves the seat

No sacrifice was made to operator comfort or safety in the 1640E Skid Loader.

• Deluxe, high-back seat standard or optional highback suspension seat provide the level of comfort required by any operator
• Unique restraint bar design equipped with Hydraloc system provides enhanced comfort and optimum safety
• Upper, side-corner instrument panel is easily visible from the operator’s seat
• ROPS/FOPS equipped with safety glass side windows, and top and rear windows to eliminate dirt and debris, enhance safety and reduce sound levels
• Standard front and rear work lights allow for enhanced visibility for night-time operation

Ergonomic controls in the 1640E Skid Loader provide smooth loader and attachment operation.

• Hand and foot throttle are standard equipment, providing quieter operation and less fuel consumption
• T-Bar hands-only drive control system

Equipped with a powerful 24-hp (17.9 kW) Yanmar diesel engine, the 1640E Skid Loader can tackle any challenge.

• Liquid-cooled for superior performance in all weather conditions
• Excellent cold weather starting with glow plug assist system

The 1640E provides 10.1 gpm (38.2 L/min) of hydraulic flow powering a variety of attachments to get work done faster.

• Direct-drive hydrostatic pump with self-neutralizing feature provides 100% efficient drive from engine to pump, requiring no maintenance
• Hydraloc™ Automatic Interlock System increases operator safety by locking lift, tilt and drive systems when the operator leaves the seat, raises the restraint bar or turns off the ignition switch
