Overview

Trip-Edge Design

Only the edge of the blade trips when an obstacle is encountered. It’s much less jarring than a full-trip blade, and because the plow blade stays upright, plowed snow remains in front of the blade.

The FISHER® trip edge uses compression-type springs. They never need adjusting and don’t stretch like extension springs.

Rugged Moldboard

4411

The steel moldboard is 27” tall, 7½' wide and features a 15½” curl radius for efficient snow rolling action.

The 75-degree attack angle is the most aggressive of any plow in its class, providing improved scraping and better back-dragging.

Reinforced Blade Structure

648

The six vertical ribs and a full-length horizontal tube provide extra stability and strength to the core of the plow blade. A pair of vertical compression trip springs delivers trip-edge protection.

Hydraulic Scrape Lock

The exclusive scrape lock feature hydraulically locks the blade down for cleaner scraping and back-dragging performance. The fast hydraulics allow you to change the blade position quickly and easily for efficient plowing.

Minute Mount® 2 Snowplow Mounting System

A simple, trouble-free attachment system available.

Its 100% mechanical design means there are no electrical components or hydraulic components to fail.

The attachment arms and lower gear are flared both vertically and horizontally to make the drive-in connection easy.

Reliable Hydraulics

We build our own hydraulics for unmatched speed and durability. Fast hydraulics allow you to change the blade position quickly and easily for efficient plowing. All critical hydraulic components are fully enclosed for protection from the elements. And the Scrape Lock feature hydraulically locks the blade down for cleaner scraping and back dragging performance.

Universal In-Cab Plow Controls

Choose between the convenient hand-held Fish-Stik® control or the compact joystick control for efficient, intuitive plow blade control.

Fish-Stik Control

The convenient hand-held control with backlit directional buttons provides precise response. Features power “on” and “float” LED and automatic shut-off.

Compact Joystick Control

The compact joystick control features a plug-in connector for easy removal and on/off indicator light.

FLEET FLEX Electrical System4479

One Truck. One Control. Any Plow.

With the FISHER® FLEET FLEX Electrical System, you have true fleet interchangeability. Unlike other manufacturers who require a different control for different plows, the FISHER FLEET FLEX system lets you operate all plows using ONE CONTROL.

Features include:

Universal Fish-Stik® Hand-held or Joystick Controls

Programmable "soft-stop" and "one-touch" float

Built-In SECURITY GUARD™ Anti-Theft System

Easy operation and increased reliability

Simple wiring and easier installation

SECURITY GUARD™ Anti-Theft System

The exclusive FISHER® SECURITY GUARD™ Anti-Theft System is a safe and secure way to electronically "lock" your snow plow while it is detached from the truck, providing a deterrent from theft or non-permitted use.

Unlike physical locks that can be cut or removed, the SECURITY GUARD Anti-Theft System electronically synchronizes your control and plow module. When activated, it disables the electronic control system and renders the snow plow inoperable to unauthorized users.

INTENSIFIRE™ Halogen Headlamps

The state-of-the-art reflector optics provide a smooth wide beam pattern that illuminates the entire plowing surface, with minimal glare above the lamp, especially during snowfall.

1,500 hour, H I 3, long-life headlamp bulb minimizes bulb replacement over the life of the lamp.

Three-screw bulb access cover attachment and twist-in headlamp bulb makes replacement quick and easy.

Lens is adhesive bonded to the reflector and the reflector is adhesive bonded to the housing, sealing out water that could potentially freeze and damage the assembly.

Robust, two-stud mounting keeps the lamp in its original mounting position – even when subjected to the harshest shock and vibration forces.

STORM GUARD™ Baked-On Powder Coat

The industry’s best protection against wear and rust. The automated climate-controlled powder booth ensures uniform coverage to all surfaces. An epoxy primer enhances powder coat adhesion and improves corrosion resistance. Plus our trademark FISHER® yellow finish is reformulated to maintain that new snow plow look even longer.
  Specifications
Blade Width Blade Height Blade Gauge Trip Springs Ribs Angling Rams Plowing Width
(Full Angle)		 Approx. Weight Wear Shoes Cutting Edge
7' 6" 2.29m 27" 68.58cm 14 1.98mm 2 2 6 + Tube 6 + Tube 1½" x 8" 3.81 x 20.32cm 6' 7" 2.01m 414 lb 188kg Optional Optional 3/8" x 6" steel
1/2" x 6" steel
1" x 6" poly 0.95 x 15.24cm steel
1.27 x 15.24cm steel
2.54 x 15.24cm poly





Specifications
Model
HT Series™
Category Name
Equipment
Year
2017
Sale Type
New
Manufacturer
Fisher
