Trip-Edge Design

Only the edge of the blade trips when an obstacle is encountered. It’s much less jarring than a full-trip blade, and because the plow blade stays upright, plowed snow remains in front of the blade.

The FISHER® trip edge uses compression-type springs. They never need adjusting and don’t stretch like extension springs.

Rugged Moldboard

Designed for ½-, ¾- and 1-ton four-wheel drive trucks, as well as today’s 15,000 GVW Super Duty vehicles, these snow plow blades are 29” high and built with the heavy 11-gauge steel (12-gauge steel for the 7½' blade). Available in 7½’, 8’, 8½’ and 9’ widths. The full base angle does not require a cutting edge, allowing for more wear. Eight vertical ribs provide superior moldboard reinforcement.

Reliable Hydraulics

We build our own hydraulics for unmatched speed and durability. Fast hydraulics allow you to change the blade position quickly and easily for efficient plowing. All critical hydraulic components are fully enclosed for protection from the elements.

Chain Lift System

With the chain lift system, you get instantaneous “float” when lowering the blade. Unrestricted, the blade can freely follow the contours of the plowing surface for a cleaner scrape.

With the chain lift you can stack higher because you’re not limited by the hydraulic ram stroke.

In the rare event of a hydraulic failure, you can push the snow plow up into a snow bank and “short chain” the snow plow by attaching it to the specially designed bracket and safely transport the snow plow back to the shop.

Universal In-Cab Plow Controls

Choose between the convenient hand-held Fish-Stik® control or the compact joystick control for efficient, intuitive plow blade control.

Fish-Stik Control

The convenient hand-held control with backlit directional buttons provides precise response. Features power “on” and “float” LED and automatic shut-off.

Compact Joystick Control

The compact joystick control features a plug-in connector for easy removal and on/off indicator light.

FLEET FLEX Electrical System

One Truck. One Control. Any Plow.

With the FISHER® FLEET FLEX Electrical System, you have true fleet interchangeability. Unlike other manufacturers who require a different control for different plows, the FISHER FLEET FLEX system lets you operate all plows using ONE CONTROL.

Features include:

Universal Fish-Stik® Hand-held or Joystick Controls

Programmable "soft-stop" and "one-touch" float

Built-In SECURITY GUARD™ Anti-Theft System

Easy operation and increased reliability

Simple wiring and easier installation

SECURITY GUARD™ Anti-Theft System

The exclusive FISHER® SECURITY GUARD™ Anti-Theft System is a safe and secure way to electronically "lock" your snow plow while it is detached from the truck, providing a deterrent from theft or non-permitted use.

Unlike physical locks that can be cut or removed, the SECURITY GUARD Anti-Theft System electronically synchronizes your control and plow module. When activated, it disables the electronic control system and renders the snow plow inoperable to unauthorized users.

The SECURITY GUARD system comes standard on the HD Series snow plow and provides a valuable tool that can be utilized at your discretion.

INTENSIFIRE™ Halogen Headlamps
