Ferris® IS® 5100Z Series

  • Ferris® IS® 5100Z Series
  • Ferris® IS® 5100Z Series
  • Ferris® IS® 5100Z Series
  • Ferris® IS® 5100Z Series
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

IS® 5100Z ZERO TURN MOWERS

The IS® 5100Z zero turn series of diesel powered zero turn mowers feature an impressive complement of comfort, performance and convenience. Easy access to service areas, impressive horsepower, enhanced lawn mowing operator comfort and increased performance all contribute to the time this zero turn mower will save you. When it comes to commercial zero turn lawn mowers, this is truly the ultimate riding and cutting machine.

 Features
  • %7BD91BC319 8AEC 4DB7 AE1E E692C78AA60F%7D Image
    Caterpillar®  Diesel
    Caterpillar® 1500cc (model 3013C) diesel lawn mower engine with 55ft/lbs of torque at 2800 rpm delivers more torque at a lower rpm for increased power when needed.
  • %7B210E5F21 12E4 41DD BE49 70523B8101BC%7D Image
    Patented Suspension
    Suspension system consists of rear dual coil-over-shocks with dual cast-iron maintenance-free suspension arms (shown) and front independent adjustable coil-over-shocks.
  • %7B78741714 5C80 4936 A8F8 6561229FB31C%7D Image
    Ride-On Mower Warranties†
    Coil-over-shocks and all suspension-related components are covered for 4 years (48 months) unlimited hours. We are committed to providing performance, productivity and durability.
  • %7B3970D80D 3F5E 476B AFB3 42DDE690DBAB%7D Image
    iCD™ Cutting System
    Innovative iCD™ Cutting System was engineered to produce the best possible cut in a multitude of conditions.
  • %7B99E08962 ABA9 425D A599 7E12AB0D6E89%7D Image
    Rear Discharge Deck
    Rear-discharge decks, used for special applications, disperse grass clippings directly behind the mower.
  • %7B34BC6F0D C8B9 4285 9CD9 1F4865E00BDC%7D Image
    Accessibility
    Automotive-style hood latch for easy service access
  • %7B5784B32D 0A14 4322 935F 6609DF9DD7F5%7D Image
    Hercules Spindles
    Hercules™ cast-iron mower spindles utilizes large 1 1⁄4" Timken®  tapered roller bearings, 1 1⁄4" shaft and 10 1⁄4" 6-bolt flange design. Long lasting, adds strength to the deck and requires minimal maintenance.
  • %7B21C82D29 2ADA 40EA BAFF 8780FDF9A1D7%7D Image
    Easy Access
    Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service.
  • %7B8F6FA3EF 7CC5 4940 92FB DF7625FA9553%7D Image
    Hydraulic Deck Lift
    Foot-activated hydraulic deck lift makes raising and lowering the deck effortless.
  • %7BDB244261 8A45 4DD7 97DB 44F169608B25%7D Image
    Miles Per Hour
    Up to 12 MPH ground speed, reverse 6 MPH.


 Specifications

MODELS IS5100ZC33D W/5100/72 IS5100ZC33D W/5100/72RD
ENGINE
Engine Brand Caterpillar®  Diesel Caterpillar®  Diesel
Rating / Displacement 33.5 gross hp^ / 1500cc 33 gross hp^ / 1500cc
PTO Electric Electric
Cylinders 3 3
Starter Electric Electric
Fuel Tank Capacity 15 gallons 15 gallons
MOWER
Cutting Width (in.) 72" (side) 72" (rear)
Cutting Height (in.) 1.5"- 6" 1.5"- 6"
Spindles Hercules™ II Cast-Iron Hercules™ II Cast-Iron
Deck Construction iCD™ Cutting System with professional lawn striper iCD™ Cutting System
SUSPENSION
Suspension Rear dual coil-over-shocks with dual cast-iron maintenance-free suspension arms and front independent adjustable shocks Rear dual coil-over-shocks with dual cast-iron maintenance-free suspension arms and front independent adjustable shocks
DRIVE TRAIN
Transmission Dual hydro pumps and wheel motors with remote oil cooler Dual hydro pumps and wheel motors with remote oil cooler
Drive Axles 1.25" 1.25"
Caster Tires (in.) 13 x 6.5-6 13 x 6.5-6
Specifications
Model
IS® 5100Z Series
Category Name
Lawn / Garden
Year
2016
Sale Type
New
Manufacturer
Ferris Mowers
Color
Red
