Fella Radon

ID # 26731681

Fella Sanos 13010 Trans

Videos
Call for Price
Overview

With transport chassis

  • Rapid and safe transport
  • Compact on the road, wide out in the field
  • Large working widths

SANOS 11008 Trans - SANOS 13010 Trans

Working width approx.: 10.20 m – 12.70 m

  1. Quiet driving behaviour on the road and low weight load from the machine to the tractor thanks to wide transport chassis.
  2. Optimised ground adaptation, even on uneven ground, since the transport wheels simultaneously function as contact wheels. Headland lifting means the tedder remains extremely agile even in small areas.
  • Large working widths with a compact design
  • Highly manoeuvrable thanks to headland raising system
  • Super C-tines
Specifications
Model
Sanos
Category Name
Agriculture
Year
2023
Sale Type
New
Manufacturer
FELLA
Rotors
10
Machine
SANOS 13010 Trans
PTO Rpm
540 rpm
Weight Approx
2160 kg
Tines Per Rotor
6
Power Demand Approx
90 hp
Working Width Approx
12700 mm
Mounting Category CAT
opt CAT
Transport Width Approx
2940 mm
Tyres Of Rotor Chassis
8x16/6.50-8 2x18.5/8.50-8
Transport Length Approx
5700 mm
Tyres Of Transport Chassis
10.0/75-15.3
Necessary Hydraulic Outlets
1xSAV / 1x DAV with floating position
special features

LARGE GROUND COVERAGE WITH LITTLE EFFORT Fella Sanos 13010 Trans

The robust chassis with large tyres means that small efficient tractors can be used. Most of the tedder's weight is borne by the transport chassis, meaning that large working widths are possible without adding extra load to the tractor.

LOW SPACE REQUIREMENT THANKS TO THE COMPACT TRANSPORT POSITION Fella Sanos 13010 Trans

Narrow driveways are no obstacle thanks to an extremely compact transport position and, furthermore, storing the rotors on the transport chassis prevents a heavy load on the hinged joints.

REVERSING AND EXTREME TURNING MANOEUVRES ARE POSSIBLE THANKS TO THE HEADLAND POSITION Fella Sanos 13010 Trans

Using simple hydraulic operation, the tedder can be raised high into the headland position. This makes it easy to reverse and provides a major advantage in the case of small plots of land and tapered areas.

CLEANER FORAGE THANKS TO THE LARGE CONTACT WHEELS Fella Sanos 13010 Trans

The transport wheels run immediately in front of the tines and scan the surface, which prevents the tines from penetrating the ground.

technologies

Super C tines

The Super C quality feature guarantees an extremely high level of quality together with an extremely long service life. As early as the manufacturing stage, special process steps are used to design the tines for toughness, elasticity and durability.

Power train

The SANOS power train with universal joints ensures consistent and reliable power transmission.

Automatic safety disconnection

When the machine is folded into the transport position, the automatic safety disconnection is activated. Damage to the drive is therefore reliably prevented.

Rotor head technology

The enclosed, maintenance-friendly rotor head from FELLA drives the SANOS tedder with a high degree of stability and cost-effectiveness.
