Overview

Rear-mounted middle attachment

  • FELLA high-performance rear-mounted mowers with middle attachment
  • Articulated shaft drive
  • Hydropneumatic cutter bar suspension system
  • TurboLift for a floating cut

RAMOS 2650 TLX-KC - RAMOS 3670 TLX-KC

Working width approx.: 2.60 m – 3.60 m

  1. The new RAMOS TLX series combines TurboLift technology for optimised ground contour following with a transportation folding system at the machine's centre of gravity (119°).
  2. The use of a conditioner allows you to obtain high-quality forage more quickly, since it speeds up moisture loss from plants.
  • Premium mower with central attachment point and robust spur gear drive
  • X-folding at the machine's centre of gravity (117-120°, depending on the working width)
  • Wide pivot travel for optimal ground adaptation
Specifications
Model
RAMOS
Category Name
Agriculture
Year
2023
Sale Type
New
Manufacturer
FELLA
Machine
RAMOS 3670 TLX-RC
PTO Rpm
1000 rpm
Mower Discs
7
Weight Approx
1500 kg
Blades Per Disc
2
Swath Width Approx
1700-2500 mm
Power Demand Approx
96 kW
Working Width Approx
3600 mm
Mounting Category CAT
II + III CAT.
Transport Width Approx
2800 mm
Transport Height Approx
3990 mm
Transport Length Approx
2100 mm
Necessary Hydraulic Outlets
1x SAV, 1x DAV
special features

OPTIMAL TRANSPORTATION FOLDING SYSTEM Fella RAMOS 3670 TLX RC

Hydraulic cylinders fold the RAMOS TLX mowers vertically towards the machine's centre of gravity, with a shock absorber minimising the impact when they reach their end position.
- The even distribution of weight on the lower link and axle allows for good stability and agility when the machine is being transported.
- The compact transportation position means that height restrictions are not a problem

GROUND ADAPTATION AND GROUND CLEARANCE Fella RAMOS 3670 TLX RC

The new boom arm design features a bend, allowing TLX mowers to achieve a wide working angle of between +28° and -20°. This optimally compensates for unevenness and height differences. An integrated compensating cylinder also prevents rocking at the headland and allows for a large ground clearance.

PROTECTED BY SAFETYSWING Fella RAMOS 3670 TLX RC

The SafetySwing impact guard, which is usually only used for large-area mowers, provides optimum safety in any field and reliably protects your machine from damage caused by striking objects. If the mower encounters an obstacle, it will fold back and away and then automatically return to its original position under its own weight.

PARK WITHOUT TAKING UP UNNECESSARY SPACE Fella RAMOS 3670 TLX RC

Practical parking supports are available as an option for RAMOS TLX mowers. These save space when parking the machinery in the transport position.

FIND THE RIGHT WORKING HEIGHT IN NO TIME AT ALL Fella RAMOS 3670 TLX RC

The practical working height indicator reduces set-up and take-down times out in the field.

ALL-ROUND PROTECTION COUPLED WITH HYDRAULICS THAT MAKE THE SYSTEM INCREDIBLY EASY TO USE Fella RAMOS 3670 TLX RC

A solid plastic strip around the guard protects against damage from minor impacts. The side-locking guard can also be folded hydraulically. The optional hydraulic transport lock completes the package.
technologies

RC roller conditioners

The mower-conditioner combination shortens the natural fermentation process of the mowed forage by hours. This gives you a decisive time advantage, particularly in unpredictable weather conditions – a quicker and safer way to produce your high-quality forage. The roller conditioner ensures intensive, yet low-impact conditioning of leafy plants such as alfalfa.

KC tine-rotor conditioners

The mower-conditioner combination shortens the natural fermentation process of the mowed forage by hours. This gives you a decisive time advantage, particularly in unpredictable weather conditions – a quicker and safer way to produce your high-quality forage. The waxy layer of the forage is rubbed off and a loose, airy swath is deposited.

SafetySwing

The SafetySwing impact guard protects every mower unit when an obstacle is encountered. This protects the mower combination against damage, thereby eliminating the need for time-consuming repairs in the workshop.

ComfortChange quick blade change

Uncomplicated quick blade change that takes only a few hand movements.

TurboLift system

The TurboLift cutter bar suspension system from FELLA guarantees continual optimum contact pressure during the entire mowing process. This protects the sward and prevents contamination of the high-quality forage. The innovative control device enables quick, easy and continuous adjustment of the contact pressure for a wide variety of operating conditions.

Spur gear drive large discs

FELLA mowers with this spur gear drive stand out thanks to a flexible range of applications as well as durable and reliable functionality with a consistently high mowing quality. The robustly designed and flat cutter bar with large mower discs combines an excellent conveying effect and even forage flow with low drag and extremely smooth running. The drive concept of the mower units stands out thanks to impressive efficiency and therefore guarantees efficient mowing under all conditions
