Trailed
|
|
Working width approx.: 10.20 m – 12.70 m
|
|
THE CLASSICS AMONG TRAILED TEDDERS
Convenient attachment to a tractor linkage drawbar is also a typical feature of this model range, as is simple and safe handling out in the field. Despite their enormous working width, these machines adapt well to uneven and hilly terrain. |
|
CAN BE HYDRAULICALLY FOLDED INTO THE TRANSPORT POSITION
Synchronised switch-over via single-acting hydraulic cylinder for increased operational convenience (Hydro versions). |
|
EDGE SPREADING DEVICE PREVENTS LOSSES OF FORAGE
The standard edge spreading device prevents forage losses at the edge of the field. By tilting the entire rotor unit, the forage is effectively thrown from the edge to the centre, meaning that it is also possible to dry forage from the shaded edges. |
| Machine | SANOS 1100 Hydro | SANOS 1300 Hydro |
|---|---|---|
| Rotors | 8 | 10 |
| Working width approx. | 10200 mm | 12700 mm |
| Tyres of rotor chassis | 16/6.50-8 | 16/6.50-8 |
| Tyres of transport chassis | - | - |
| Weight approx. | 1090 kg | 1305 kg |
| Power demand approx. | 48 hp | 61 hp |
| Mounting Category | Drawbar | Drawbar |
| Necessary hydraulic outlets | 1x SAV | 1x SAV |
| Transport width approx. | 2780 mm | 2780 mm |
| Transport length approx. | 6830 mm | 8070 mm |
| PTO rpm | 540 rpm | 540 rpm |
| Tines per rotor | 6 | 6 |
