Fella Ramos 210 FK-S - Ramos 260 FK

  • Fella Ramos 210 FK S Ramos 260 FK
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Front-mounted compact linkage

  • Specialists for alpine terrain
  • Short, compact attachment to the tractor
  • Lightweight construction
Working width approx.: 2.05 m – 2.50 m
  1. Rigid headstock with short, compact attachment and a centre of gravity near to the tractor for optimum efficiency on slopes.
  2. The alpine front-mounted mowers can be combined with many tractors thanks to the standard 540 and 1000 rpm as well as clockwise and anti-clockwise rotation.
Specifications
Model
Ramos 210 FK-S - Ramos 260 FK
Category Name
Agriculture
Year
2021
Sale Type
New
Manufacturer
FELLA
special features

RIGID HEADSTOCK FOR SHORT, COMPACT TRACTOR ATTACHMENT Fella Ramos 210 FK S Ramos 260 FK

The short, compact attachment ensures that the centre of gravity is close to the tractor and guarantees optimum efficiency on slopes in alpine terrain.

SYMMETRICAL, CENTRAL RUNNING THANKS TO FOUR MOWER DISCS Fella Ramos 210 FK S Ramos 260 FK

The four mower discs on these types of mower ensure symmetrical, central running, which allows excellent and uniform swath positioning. This has an excellent impact on the conveying effect in downhill operation.

SPRING-LOADED IMPACT GUARD SYSTEM Fella Ramos 210 FK S Ramos 260 FK

The spring-loaded impact guard system ensures optimum protection of the mower if an obstruction is encountered when driving.

LATERAL MOVEMENT OF THE FK-S VARIANT

The lateral movement of the FK-S variant (hydraulic optional) makes mowing on slopes and/or with twin tyres possible without problems.

UNEVEN GROUND COMPENSATION THANKS TO PIVOT TRAVEL Fella Ramos 210 FK S Ramos 260 FK

The pivot travel of +9° compensates for uneven ground on alpine terrain without difficulty.
technical specifications
Machine RAMOS 260 FK RAMOS 210 FK-S RAMOS 260 FK
Mounting category CAT. I CAT. I CAT. I CAT.
Working width approx. 2500 mm 2050 mm 2500 mm
Weight approx. 410 kg 373 kg 410 kg
Blades per disc 2 2 2
Power demand approx. 30 hp 26 hp 30 hp
Mower discs 4 4 4
Swath width approx. 1350 mm 1100 mm 1350 mm
Transport width approx. 2500 mm 2080 mm 2500 mm
Transport length approx. 1290 mm 1180 mm 1290 mm
PTO rpm 540/1000 rpm 540/1000 rpm 540/1000 rpm
