FELLA JURAS 12545 PRO

  • FELLA JURAS 12545 PRO
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Rakes

JURAS

4000 - 12545 PRO

  • Hydraulic working width/swath width adjustment
  • Performance and low drag in one machine
  • Durable  FELLA rake head  with enclosed design
Satz 6 gr2016 2000px
JURAS 4000: PERFORMANCE AND LOW DRAG
The model was developed specifically to achieve what it was designed for – high cutting power, low weight and simple operation. No more, no less. Thanks to its simple yet very stable structure, the JURAS 4000 is very easy to operate and maintain. Even new drivers can use the JURAS 4000 safely and efficiently, which increases its flexibility especially when used on more than one farm.

















SEQUENTIAL CONTROL AS STANDARD: EASY TO OPERATE ON THE HEADLAND
The JURAS four-rotor rakes are equipped with automatic, hydraulic and individually adaptable sequential control. This system controls the delayed raising and lowering of the rear pair of rotors and, as a result, enables you to deposit perfectly formed swaths at the end of the field.
Satz 6 gr2016 2000px


















Satz 6 gr2016 2000px JURAS 12545 PRO: OPERATION OF ALL FUNCTIONS USING ISOBUS CONTROL SYSTEM
All functions, such as single lift, raking height adjustment and automatic folding into the transport position, can be operated from the tractor using the ISOBUS control system and can be programmed according to the user's needs using the control lever or a separate operating joystick.
JURAS 12545 PRO: MEASURE PERFORMANCE WITH THE INTEGRATED HECTARE COUNTER
Using the integrated hectare and hour counters, it is possible to measure the amount of work which has been done. Ideal for paid contract work or use on more than one farm.
Satz 6 gr2016 2000px

HYDRAULIC WORKING WIDTH ADJUSTMENT
This ensures optimum ergonomics and, as far as possible, makes the driver's work easier after a long working day.













Satz 6 gr2016 2000px














Satz 6 gr2016 2000px
TRANSPORT CHASSIS DESIGNED FOR 40 KM/H
The driver can reach speeds of up to 40 km/h with the transport chassis (depending on permissions in the country). Wasting time when transferring from one field to another is now a thing of the past.























Specifications
Model
JURAS 12545 PRO
Category Name
Agriculture
Year
2020
Sale Type
New
Manufacturer
FELLA
PTO Rpm
540 rpm
Rotor Diameter
3200 mm
Weight Approx.
4650 kg
Swath Width Approx.
1200-2200 mm
Tine Arms Per Rotor
4x 12
Double Tines Per Arm
4
Power Demand Approx.
80 hp
Working Width Approx.
12500 mm
Mounting Category CAT.
II CAT.
Tyres Of Rotor Chassis
4 x 16/6.50-8 / 6 x 16/6.50-8
Transport Length Approx.
8720 mm
Transport Width Approx. (mounted Tine Arms)
- mm
Transport Height Approx. (dismounted Tine Arms)
3650 mm
