FELLA JURAS 1402

  • FELLA JURAS 1402
  • FELLA JURAS 1402
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Rakes

JURAS

1452 - 1603




  • Can be adapted to the forage volume using single- or double-swath positioning
  • Precise  SteerGUARD  steering system
  • Durable  FELLA rake head  with enclosed design

CAN BE ADAPTED TO FORAGE VOLUME USING SINGLE- OR DOUBLE-SWATH POSITIONING



Satz 6 gr2016 2000px


















Satz 6 gr2016 2000px
SEQUENTIAL CONTROL FOR EXACT SWATHS AT THE END OF THE FIELD
The machines are equipped with automatic, hydraulic and individually adaptable sequential control. This system controls the delayed raising and lowering of the rotors and makes it possible to form perfect swaths at the end of the field.
Satz 6 gr2016 2000px
TRANSPORT CHASSIS DESIGNED FOR 40 KM/H
The driver can reach speeds of up to 40 km/h with the transport chassis (depending on permissions in the country). Wasting time when transferring from one field to another is now a thing of the past.
Satz 6 gr2016 2000px

LARGE ROTOR OVERLAP FOR NEAT FORAGE HANDOVER
All FELLA side rakes have a large overlap between the first and the second rotor. This ensures neat forage handover and swath formation even under difficult working conditions, such as turning around corners or very large amounts of forag






















Specifications
Model
JURAS 1402
Category Name
Agriculture
Year
2020
Sale Type
New
Manufacturer
FELLA
PTO Rpm
540 rpm
Rotor Diameter
2740 / 2780 mm
Weight Approx.
1550 kg
Swath Width Approx.
600-1900 mm
Tine Arms Per Rotor
10/12
Double Tines Per Arm
4
Power Demand Approx.
26 hp
Working Width Approx.
5750 / 6650 mm
Mounting Category CAT.
I+II CAT.
Tyres Of Rotor Chassis
3x 16/6.50-8
Transport Length Approx.
6630 mm
Transport Width Approx. (mounted Tine Arms)
3600 mm
Transport Width Approx. (dismounted Tine Arms)
3000 mm
