Overview

Disc-mowers
RAMOS

  • Light and robust construction ideal for smaller tractors
  • Easy handling and foldable protective sheets for good accessibility
  • Extremely flat cutter bar with spur gear drive
 Special Features
Effortless adjustment of the cutter bar to the terrainhttps://fella.eu/images/products/02_trommelmaehwerke_radon/Querpendelbewegung_Pendelbock_COMP_v001_1000px.jpg

Thanks to the 30° pivot angle of the mower unit cutter bar, it is also possible to work neatly on ditches and slopes. The oil maintenance of the cutter bar is designed in such a way that reliable lubrication of all components is guaranteed at all times.

The mower is protected by a spring-loaded impact guard system

The spring-loaded impact guard system provides optimum protection for the mower if an obstruction is encountered when driving. Reversing automatically re-engages the mower unit in the working position.
Cutter bar with spring relief as standardhttps://fella.eu/images/products/10_scheibenmaehwerke_ramos/SM_9314_TL-KCB_arb_print_9_gr2016_1000px.jpg

The mechanical spring relief has a very quick response rate when working and ensures extremely good ground contour following of the cutter bar, protection of the sward and, therefore, clean and high-quality forage.
Easy cleaning and maintenance Headstock with trailing linkage transverse pivot movement COMP v001 72dpi 1000px

The FELLA InLine mowers feature a protective sheet which can be folded on both sides for good accessibility during cleaning and maintenance work.





Specifications
Model
RAMOS 288 InLine
Category Name
Agriculture
Year
2020
Sale Type
New
Manufacturer
FELLA
PTO Rpm
540 rpm
Mower Discs
7
Weight Approx
475 kg
Blades Per Disc
2
Transport Height
3610 mm
Swath Width Approx
2000 mm
Power Demand Approx
60 hp
Working Width Approx
2820 mm
Mounting Category CAT
I+II CAT.
Transport Width Approx
1730 mm
