Fella Radon

ID # 13978788

Fella Ramos 9314 TL-KCB

Videos
Call for Price
Overview

Disc-mowers
RAMOS

  • Work process automation with ISOBUS control system
  • Optimum swath gathering with the FELLA beMOVE conveyor belt
  • Perfect quality of cut thanks to the cutter bar with compact angular gear
 Special Features
Operation of all functions using the ISOBUS control systemhttps://fella.eu/images/products/02_trommelmaehwerke_radon/Querpendelbewegung_Pendelbock_COMP_v001_1000px.jpg

All functions, such as single lift, conveyor belt operation and the slope function, can be operated from the tractor using the ISOBUS control system and can be programmed according to the user's needs using the control lever or a separate control joystick.
This ensures optimum ergonomics and, as far as possible, makes the driver's work easier after a long working day.

Automatic folding for transport https://fella.eu/images/products/14_scheibenmaehwerke_ramos/Gleitf%C3%BChrung_S.31_IC3.jpg

At just a touch of a button, the mower automatically and neatly folds into the transport position. Once the mower combination is at a standstill, the conveyor belts are securely and automatically brought into position.

Combination of front-mounted mower and rear unit

Fully automated work processes mean that the front-mounted mower and the rear units can be combined at just a touch of a button. Both mower units can be lowered and lifted sequentially.

Speed sensors in the entire power trainhttps://fella.eu/images/products/10_scheibenmaehwerke_ramos/SM_9314_TL-KCB_arb_print_9_gr2016_1000px.jpg

The user can conveniently monitor the speed of the mower combination from the driver's seat and is also immediately notified of any faults by an automatic warning function. The mower combination can be used to maximum capacity in this manner.

beMOVE – hydraulic lateral movement for conveyor belts Protective sheet that folds on both sides

The belt speed of the wide conveyor belt (940 x 270 mm) with integrated hydraulic lateral movement can be adjusted infinitely.
Optimum swath gathering is possible via ISOBUS, even in bulky crops.
The swath width can be adjusted to the trailing machinery variably and easily from the comfort of the driver's seat.



Specifications
Model
Ramos 9314 TL-KCB
Category Name
Agriculture
Year
2018
Sale Type
New
Manufacturer
FELLA
Mower Discs
2x 7
Mounting Category CAT
II+III CAT.
Working Width Approx
9300 mm
Weight Approx
3450 kg
Power Demand Approx
228 hp
Swath Width Approx
1800-3000 mm
Transport Width Approx
2780 mm
PTO Rpm
1000 rpm
Blades Per Disc
2
Of Which With Conveyor Wings
4
Transport Height
3900 mm
