Overview

Disc-mowers
RAMOS

  • Mower hitched in the middle with integrated slide track
  • Floating cut thanks to the TurboLift system
  • Perfect quality of cut thanks to the cutter bar with compact angular gear
 Special Features
Low-drag thanks to intelligent hitch attachmenthttps://fella.eu/images/products/02_trommelmaehwerke_radon/Querpendelbewegung_Pendelbock_COMP_v001_1000px.jpg

The mower units mounted at the centre of gravity relieve the lifting arms, ensure excellent ground adaptation and save fuel as a result of uniform contact pressure.

Optimum guidance of the cutter bar thanks to the FELLA slide track https://fella.eu/images/products/14_scheibenmaehwerke_ramos/Gleitf%C3%BChrung_S.31_IC3.jpg

The patented FELLA slide track provides optimum stability and guidance of the cutter bar both longitudinally and transversely. This relieves the load on the mower's lifting arm and allows for even better ground adaptation.

The mower is protected by an impact guard system https://fella.eu/images/products/14_scheibenmaehwerke_ramos/SM_3570_TL-KCAnfahrsicherung.jpg

The mower is optimally protected thanks to the precisely adjustable release force on the brackets. A double-acting hydraulic cylinder returns the mower to the working position when the working position is activated from the tractor cab.
Tools and spare blades always at handhttps://fella.eu/images/products/10_scheibenmaehwerke_ramos/SM_9314_TL-KCB_arb_print_9_gr2016_1000px.jpg

The spacious tool box is fitted on the headstock of the mower for easy access. This means that spare blades and/or tools are always within reach.

Upward-folding full-cloth guard Protective sheet that folds on both sides

The TL mowers are fitted with a protective sheet that folds on both sides for easy access during cleaning and maintenance work.



Specifications
Model
Ramos 4590 TL
Category Name
Agriculture
Year
2018
Sale Type
New
Manufacturer
FELLA
Mower Discs
9
Mounting Category CAT
II+III CAT.
Working Width Approx
4500 mm
Weight Approx
1100 kg
Power Demand Approx
84 hp
Swath Width Approx
3800 mm
Transport Width Approx
2300 mm
Transport Length Approx
6100 mm
PTO Rpm
1000 rpm
Blades Per Disc
2
