ID # 13976012

Fella Ramos 3060 FP

  • Fella Ramos 3060 FP
  • Fella Ramos 3060 FP
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Disc-mowers
RAMOS

  • The quick-change blade system, storage facilities for both spare blades and the quick-change blade system key, plus the 180° folding range of the side guards, make the mowers easier to use
  • Optimum ground adaptation by hitching the mower unit at the centre of gravity
  • Sophisticated design
 Special Features
Optimum ground adaptationhttps://fella.eu/images/products/02_trommelmaehwerke_radon/Querpendelbewegung_Pendelbock_COMP_v001_1000px.jpg

The pivot axle mounted at the centre of gravity ensures optimum ground adaptation (+/- 6.5°). A uniform cutter bar contact pressure can be set using the spring relief on the tractor.

Low load for the tractor

Due to the compact linkage on the FP mower, the centre of gravity is very close to the tractor. This results in a low load for the tractor and machine, and prevents rocking, even when driving quickly on roads.
Uniform swath positioning

The symmetrical number of mower discs ensures that swath is uniformly positioned between the tractor tyres without additional feeder drums or swath drums.

PERFECT SWATH POSITIONING FOR THE LOADER WAGON
RAMOS disc mower with transverse pivot movement

The FP-SL swather variant with cam-controlled feed tines ensures swaths are deposited in defined, compact lines (< 1.10 m depending on type of forage and crop). The feed tines deposit a precisely shaped and lightly packed swath which is suitable for all pick-up widths.

RETAINER FOR QUICK-CHANGE BLADE SYSTEM KEY

Ramos 3060FP Klingenwechsler 005

The quick-change blade system tool is close at hand.

BLADE BOX Ramos 3060FP Messerkiste 012

The blade box keeps spare blades safe and ensures that they are always within easy reach.

SIDE-LOCKING, FOLDING PROTECTIVE COVERS DESIGNED FOR OPTIONAL USE WITH A HYDRAULIC FOLDING SYSTEM

Ramos 3060FP klappen 001

In order to comply with the transport width of 3 metres, the side guard cover can be folded. The design allows for optional use with a hydraulic side guard folding system, which reduces set-up and take-down times.





Specifications
Model
Ramos 3060 FP
Category Name
Agriculture
Year
2020
Sale Type
New
Manufacturer
FELLA
PTO Rpm
1000 rpm
Mower Discs
6
Weight Approx
770 kg
Blades Per Disc
2
Swath Width Approx
2000 mm
Power Demand Approx
75 hp
Working Width Approx
3000 mm
Mounting Category CAT
II CAT
Transport Width Approx
3000 mm
Transport Length Approx
1490 mm
