WIDER WORKING WIDTHS

The 400 series differs from the 300 series due to its large-dimensioned rake head and the larger working width that comes as a result. With up to 12 tine arms and 48 tines, tidy and even raking is always guaranteed for working widths of up to 4.50 m. The series features a very sturdy design, ease of handling and excellent manoeuvrability due to its standard trailing device.

SWATHS

Very exact swaths are possible even with a large forage mass thanks to the extra strong tine arms and the long tines. Thanks to a cam track that can be adjusted on the outside, optimal swath formation is guaranteed at all times for all follow-up devices. In addition, the width of the swath can be adapted to your requirements using the infinitely adjustable swath former.

PERFECT GROUND FOLLOWING

Thanks to the wide-track chassis and movable lower link bracket, optimum ground adaptation is guaranteed, even for large working widths. These models are particularly well suited to hillsides.

DRIVE

The drive is via single-stage bevel gear with a split double bearing pinion shaft. In addition, the gear box and cam track are enclosed and dust-tight, which guarantees a long service life.



At a glance:

• Single-rotor rake with trailing device
• Large working widths
• Tidy raking and therefore first-class swath formation
• Perfect ground contour following
• Good on hillsides
• Sturdy, dust-tight, triple bearing drive
• One-piece, D-shaped three-point headrack
• Adjustable lateral inclination
• Infinitely adjustable cloth
