Farm King Rotary Tiller

Call for Price
Overview
Farm King has a collection of rotary tiller models to suit your garden and landscaping needs. The tiller attaches to the 3-point hitch and is designed to fit a variety of tractors, from 12 hp to 65 hp. Tilling
Rt Mainwidths range from 36" to 54" in the 25 Series and from 55" to 69" in the 45 Series. The 65 Series is available in 68" and 77" widths.
  Features
Break ground with ease
The tilling shaft is equipped with four to eight flanges, depending on the model. Flanges on all series are available with four tines, and six tines per flange are standard on the 65 series. This provides on optimum balance between performance and durability, even in heavy soils and when breaking untilled soil.

Set the right depth
Standard on all Farm King Rotary Tillers, the skid shoes are adjustable so it is easy to set the perfect tilling depth.

Low maintenance, long life
The automatic chain tightener is standard on all models. This ensures the chain remains tight even under the toughest tilling conditions. Housed within a sealed oil bath, the chain tightener is designed to be reliable and maintenance-free.

Get closer to the edge
Getting close to the fences, hedges or covering a tire track is easy with the sideshift feature. The entire unit can be pushed to one side, while the PTO shaft remains in line with the tractor to minimize stress on the universal joint. The sideshift feature is available on all Farm King Rotary Tillers except the 6582.
Specifications
Series
25


45

Model
2540
2548
2560
4560
4572
Tillage width
36"
45"
54"
55"
69"
Overall width
46-1/2"
54-1/2"
66-1/2"
66"
78"
Tractor engine requirements
12 - 18 hp
14 - 22 hp
18 - 25 hp
25 - 40 hp
30 - 45 hp
3-point hitch
Cat. 1
Cat. 1
Cat. 1
Cat. 1
Cat. 1
Gearbox
Heavy-duty oil bath (540 RPM)




Chain in oil bath
#60H
#60H
#60H
#80H
#80H
Rotor speed RPM
196 RPM or 880 ft/min


203 RPM or 865 ft/min
Sideshift
2-1/2"
4-1/2"
7-1/2"
6-3/4"
8-1/2"
PTO shaft
Slip clutch, shear bolt optional


Slip clutch

Tine size
1/4" x 2-1/4"
1/4" x 2-1/4"
1/4" x 2-1/4"
1/4" x 2-1/4"
1/4" x 2-1/4"
Number of tines
4 flanges
4 tines/flange
5 flanges
4 tines/flange
6 flanges
4 tines/flange
6 flanges
4 tines/flange
8 flanges
4 tines/flange
Skid shoes
Standard
Standard
Standard
Standard
Standard
Weight
425 lb
458 lb
517 lb
613 lb
688 lb



Series
65
Model
6572
6582
Tillage width
68"
77"
Overall width
78"
88"
Tractor engine requirements
45 - 55 hp
55 - 65 hp
3-point hitch
Cat. I, optional fit Cat. II
Gearbox
Heavy-duty oil bath (540 RPM)
Chain in oil bath
#100H
#100H
Rotor speed RPM
196 RPM or 880 ft/min
Sideshift
15"
n/a
PTO shaft
Slip clutch
Tine size
5/16" x 3-1/4"
5/16" x 3-1/4"
Number of tines
7 flanges
6 tines/flange
4 tine opt.
8 flanges
6 tines/flange
4 tine opt.
Skid shoes
Standard
Standard
Weight
906 lb
968 lb















Specifications
Model
Rotary Tiller
Category Name
Tractor Attachments
Year
1999
Sale Type
New
Manufacturer
Farm King
