Overview

EASY RAKE SUPERSTAR Pull Type "V" Rake

Big productivity begins here. Our ERS 20 model reaches 38 ft. of working width.
The autosteer system enables the machine to work with ease in small plots and the shock absorbers ensure shock-free operations on uneven terrain.
IDEAL FOR : medium to big farms.

KEY FEATURES : A unique design in the world. Enorossi obtains the invention patent in the USA. The heavy frame and high profile of the BATRAKE give a full 32” of ground clearance allowing it to rake on all types of ground contours in heavy hay conditions.

DESCRIPTION : Enoagricola Rossi now offers the latest innovation in High Capacity Caddy rakes with the BATRAKE. The heavy 6,9 mm. spring tines provide for excellent wear and strong resistance to breakage.
Go from a V rake configuration to single side without leaving the tractor seat.
The BATRAKE’s unique lifting system gives you the ability to only partially raise the V-rake when coming to the end of the field, rather than into the full transport position. A single hydraulic hose allows it to be used on older tractors with limited hydraulic remotes. Windrows width from 3’ to 7’.
This unique V-rake combines attention to detail and quality of the work performed. The Batrake's raking wheels can be considered among the best on the market. with 32 inc. of ground clearance!
Central raking wheel with hydraulic lift, hydraulic raking angle control and road homologation available upon request.

WITH THIS MACHINE THE USER WILL NEVER LEAVE THE TRACTOR SEAT DURING ALL OPERATIONS!

MODELS : Available in 8 - 10 and 12 wheel sizes, the BATRAKE pull type V-rake comes in either Double Wheel or Single Wheel configurations.
 TECHNICAL SPECIFICATIONS
  • Optional hydraulically raised kicker wheel available for all sizes.
  • Adjustable pressure spring.
  • Single hydraulic hose.
  • Patented pressure variable springs on the single wheel configuration keep ideal pressure on each raking wheels at all times.
  • Frames made of FE 510 steel.
  • Lateral frame sections 100 mm x 80 mm, 4 mm thickness.
  • Pull bar sections 150 mm x 80 mm, 4 mm thickness.
  • Raking wheels made of C85 heat tempered steel to ensure stability and durability over time.
  • Raking wheels Ø 140 cm, with central flange Ø 3,5 mm, n° 40 teeth Ø 6,9 mm.
  • Transport Tires 205.70/15.
  • Wheel Tines 6,9 mm.
  • Raking wheels hubs made of spheroidal cast iron with grease zerk.
  • V-Rake wheel arms with torsion spring to adjust the ground pressure.
  • Hydraulic cylinders with simple effect for lifting side frames.
  • Windrow width adjustment by using mechanical tensioners or hydraulic cylinders upon request.
  • Possibility to operate just one side, without adding any additional kit.
  • Hydraulic kicker wheel with N° 1 raking wheel, Ø 110 cm.
  • Independent rake wheels.



Specifications
Model
BATRAKE 8
Category Name
Agriculture
Year
2015
Sale Type
New
Manufacturer
Enorossi
Transport Width
250 cm. 8.2 ft.
Weight
680 Kg. 1.237 Lbs.
Working Width
500-560 cm. 16-18 ft.
N° Wheels
2
Transport Lenght
535 cm. 18 ft.
Power Required
30 HP
