Overview
 Premium diesel performance. Maximum comfort and productivity. Legendary durability.
For a variety of reasons, the redesigned diesel-powered Lazer Z zero-turns may be the right choice for your cutting needs. They make quick work of the largest, toughest jobs and raise the bar for cut quality, operator comfort, fuel efficiency and ease of handling. Our large 96-inch flex wing deck is capable of mowing over 9.5-acres per hour, making it the most productive mower Exmark has ever built.
Features
124Improved Handling
The engine and radiator have been placed lower to the ground in the redesigned Lazer Z Diesel. This provides an even lower center of gravity leading to improved traction and a smoother ride.
125Reduced Maintenance and Service
With an efficient and robust powertrain system, in addition to eliminating drive belts, these machines have less maintenance and longer service intervals. And the tool-less belt access and removable floor pan makes servicing easy.
125Fuel Capacity
For longer work intervals, the Lazer Z Diesel has a 12.0-gallon capacity with two tanks. This will keep you mowing longer with fewer fill-ups.
125Hydraulic Deck Lift
Standard on all diesel units, the hydraulic deck lift provides for easy cutting height adjustment and quick transport.
125Tire Size / Ground Speed
The 26" x 12"-12" drive tires allow you to reach speeds up to 12.5 mph on machines equipped with the 1.6 Liter Common Rail engine. The large drive tires also provide superior traction and handling, giving you the ability to manage diverse terrain and conditions.
125Productivity
The robust engine power and large deck sizes make these mowers Exmark's most productive diesel machines ever. They are a great solution for universities, municipalities and other sizeable properties.
125On-Board Intelligence
The next generation RED leverages the latest technologies to deliver increased machine efficiency, ease of use and durability. This technology provides users an increased ability to control mower power and efficiency with defined performance modes.
Icon PartsOnly200Leading Zero-Turn. Strong Warranty
Purchase an Exmark Lazer Z Diesel mower with confidence by taking advantage of the protection Exmark provides for you with our five year limited warranty. Now standard on all Exmark Lazer Z Diesel mowers sold in the U.S. or Canada. For complete details, visit your local dealer.
  LZS80TDYM604W0 LZS80TDYM724W0 LZS80TDYM72RW0
Steering Control Hydraulically dampened twin levers, adjust fore and aft., also adjustable to 2 height positions. Adjustable dampeners (3 positions) to customize drive responsiveness. Hydraulically dampened twin levers, adjust fore and aft., also adjustable to 2 height positions. Adjustable dampeners (3 positions) to customize drive responsiveness. Hydraulically dampened twin levers, adjust fore and aft., also adjustable to 2 height positions. Adjustable dampeners (3 positions) to customize drive responsiveness.
Casters .50" thick caster yoke arms. .50" thick caster yoke arms. .50" thick caster yoke arms.
Drive Tires 26x12-12, 6ply Multi Trac® 26x12-12, 6ply Multi Trac® 26x12-12, 6ply Multi Trac®
Parking Brake Lever-actuated internal wet disc brake. Lever-actuated internal wet disc brake. Lever-actuated internal wet disc brake.
Electrical 12-volt battery with 55-amp alternator. 12-volt battery with 55-amp alternator. 12-volt battery with 55-amp alternator.
Engine Model 3TNV80FT 3TNV80FT 3TNV80FT
Engine Brand Yanmar Yanmar Yanmar
Engine Speed 2,600 RPM 2,600 RPM 2,600 RPM
Speed Infinitely variable speed selection from 0–11.0 mph (18 kmph) forward, 0–6 mph (10 kmph) reverse. Infinitely variable speed selection from 0–11.0 mph (18 kmph) forward, 0–6 mph (10 kmph) reverse. Infinitely variable speed selection from 0–11.0 mph (18 kmph) forward, 0–6 mph (10 kmph) reverse.
Fuel Capacity 12-gallon (45.4-L), side fuel tanks 12-gallon (45.4-L), side fuel tanks 12-gallon (45.4-L), side fuel tanks
Deck Style Floating Deck Floating Deck Floating Deck
  LZS88CDYM604W0 LZS88CDYM724W0 LZS88CDYM96RW0
Steering Control Hydraulically dampened twin levers, adjust fore and aft., also adjustable to 2 height positions. Adjustable dampeners (3 positions) to customize drive responsiveness. Hydraulically dampened twin levers, adjust fore and aft., also adjustable to 2 height positions. Adjustable dampeners (3 positions) to customize drive responsiveness. Hydraulically dampened twin levers, adjust fore and aft., also adjustable to 2 height positions. Adjustable dampeners (3 positions) to customize drive responsiveness.
Casters .50" thick caster yoke arms. .50" thick caster yoke arms. .50" thick caster yoke arms.
Drive Tires 26x12-12, 6ply Multi Trac® 26x12-12, 6ply Multi Trac® 26x12-12, 6ply Multi Trac®
Parking Brake Lever-actuated internal wet disc brake. Lever-actuated internal wet disc brake. Lever-actuated internal wet disc brake.
Electrical 12-volt battery with 55-amp alternator. 12-volt battery with 55-amp alternator. 12-volt battery with 55-amp alternator.
Engine Model 3TNV88C 3TNV88C 3TNV88C
Engine Brand Yanmar Yanmar Yanmar
Engine Speed 3,000 RPM 3,000 RPM 3,000 RPM
Speed Infinitely variable speed selection from 0–12.5 mph (20 kmph) forward, 0–7 mph (11 kmph) reverse. Infinitely variable speed selection from 0–12.5 mph (20 kmph) forward, 0–7 mph (11 kmph) reverse. Infinitely variable speed selection from 0–12.5 mph (20 kmph) forward, 0–7 mph (11 kmph) reverse.
Fuel Capacity 12-gallon (45.4-L), side fuel tanks 12-gallon (45.4-L), side fuel tanks 12-gallon (45.4-L), side fuel tanks
Deck Style Floating Deck Floating Deck Floating Deck




Specifications
Model
Exmark Lazer Z Diesel
Category Name
Lawn / Garden
Year
2018
Sale Type
New
Manufacturer
Exmark
