| DEUTZ-FAHR has always been one of the leading |
|
Features |
|
Engine
Extraordinary power with impressive fuel economy.
Three and four cylinder Turbo Intercooler engines with a Engines offering exactly the right amount of power for the job: the 1 litre size is the best compromise today between smaller, sub-litre configurations, which are very compact but underpowered, and conventional larger engines with capacities above 1,000 cc. 82 hp/60 kW, 85 hp/63 kW, 90 hp/66 kW, 96 hp/71 kW and 106 hp/78 kW engine variants are equipped with an intercooler, which cools the air compressed by the turbocharger, increasing the mass of air delivered to the cylinders and improving combustion. This considerably increases power and reduces fuel consumption, while maintaining lower engine operating temperatures. Much more advanced than conventional rotary pump systems, the exclusive SDF injection system with individual pumps for each cylinder maximises engine power (with very high injection pressures of up to 1,400 bar) and ensures extremely short injection times, while the electronic engine management system varies the injection timing itself in relation to load to optimise consumption. An electronic governor lets the driver set and store an engine speed, which the electronic control unit then maintains at a constant value in any condition and even with varying load, for constant, uniform results. The engines powering Agroplus V/S/F models use an innovative exhaust gas recirculation system, to achieve compliance with Tier III emissions regulations. |
|
Transmission Power and versatility under total control.
|
|
PTO
A range of speeds to choose from.
|
|
Hydraulic System
Total precision and simplicity of use.
|
|
Brakes
Safety and agility.
The compact design of the tractor, innovative front axle For maximum traction even in the most challenging terrain conditions, Agroplus V/S/F tractors are equipped with an exclusive and specifically developed AUTO 4WD system, allowing the driver to engage and disengage four wheel drive with extreme ease. All Agroplus versions feature an integral all-wheel braking system, with low wear wet disc brakes on all four wheels for superlative stopping power in all conditions - even on steep gradients or at high speed. The maximum steering angle permitted by the smooth, nimble steering system differs according to model: with a steering angle of 50 degrees for the F, 60 degrees for the 4WD V and S versions, and 70 degrees for the 2WD Agroplus S and Agroplus F variants. |
|
Cab
Size matters: both inside and out.
|
