Engine



Top-of-the-line for power and efficiency



The 9 series comprises the new 6-cylinder DEUTZ TTCD 7.8 L6 engine with four valves per cylinder, DCR (DEUTZ Common Rail) injection system with built-in electronic management, twin turbo chargers and intercooling. Efficiency and consumption are minimised even further with the electronically controlled cooling system. With a fuel tank capacity of 6001 (AdBlue 60 l) even the longest working days are managed without compromise. The 9 Series also adopts the SCR catalytic converter, together with the DPF for post treatment of exhaust gases: the most advanced system with regard to the environment and meeting full compliance for Tier 4 final.



The 9 Series uses the new ZF Terramatic TMT 32 continuously variable transmission with four mechanical ratios that offers riding comfort, efficiency and economical operation that know no equal under any conditions, both in the field and on the road. Offering a maximum speed of 60 km/h at just 1,780 rpm (50 km/h at 1,480 RPM and 40 km/h at 1,350 rpm with the legal limitations). The semi-active automatically controlled suspensions guarantee that driving is always dynamic and fluid. The PowerBrake and EPB (Electric Parking Brake)system, offer safe, powerful and efficient braking in all conditions. Disc brakes on the front axle are also available as an option.

Hydraulic System



210 litres per minute for comprehensive operation



The 9 Series has a powerful closed-circuit hydraulic system and load sensing pump operating at 210 L per minute and operating at 200 bars with six auxiliary distributors (four at 150 l/min and 2 at 100 l/min) all with electronically controlled capacities and timing. The impressive hydraulic performance is complimented with are rear lift capacity of 12000k

Cab



Work at your best



The 9 Series' Maxi-Vision cab allows maximum visibility and thanks to total insulation, it guarantees unequalled acoustic comfort.  Inside, high-quality materials like the Soft Grip steering wheel and the ergonomic arrangement of the controls set around the driver intuitively offer a pleasant working environment. Standard specification also includes pre disposition for Agrosky Autosteering, IMonitor 2 and ISOBUS offering the operator unrivalled efficiency.
