Overview
 Flex Hoe™ Air Drills
Case IH Flex Hoe Series air hoe drills offer the size, configuration and precision you need.

Seeding Style Options for Any Application Seeding Style Options for Any Application

Case IH Flex Hoe Series air hoe drills are engineered to deliver precision seeding under a wide variety of seeding styles and field conditions. Click "See More" to learn how the Flex Hoe Air Drill can be configured to match the seeding style best suited for your operation.

Match the Right Opener to Your Conditions Match the Right Opener to Your Conditions

Higher yields can be gained when you match the right opener to your conditions to achieve accurate seed and fertilizer placement. Case IH offers two openers -- Stealth® and Nok-on™that deliver successful seeding in your conditions.

Wide Range of On-Row Packing Choices Wide Range of On-Row Packing Choices

To improve germination, Case IH offers a wide range of on-row packing choices to match your seeding style, opener and soil conditions. You can choose from steel, pneumatic or semi-pneumatic packing wheels--each geared to fit specific conditions.

Two Shank Styles and Two Trip Options Two Shank Styles and Two Trip Options

Match shank and trip styles to your operation so you protect valuable openers, get maximum clearance for tripping over obstacles and effective penetration for consistent depth. Choose from two shank styles and two trip options to create the air drill that's right for your operation.


 Flex Hoe™ 700 Highlights
The Flex Hoe 700 is available in either a 60 ft (18.3 m) or 70 ft (21.3 m) width with shank spacing ranging from 7.2 in to 12 in (18.3 cm to 30.5 cm).
  • Base sizes include 60 and 70 ft. (18.3 and 21.3 m), which fold down to a transport width of 17 ft. 8 in. (5.4 m)
  • A strong mainframe of large, 12x12-in. (30.5x30.5-cm) steel tube with 10-ft. center section and either 10- or 15-ft. flexwings that hug the terrain
  • A patented two-piece wing allows for precise depth — front-half depth is controlled by a nearby caster assembly, and rear-half depth is controlled by press wheels
  • Variable packing pressure adjusts to conditions that change from field to field
Specifications
Model
Flex Hoe 700
Category Name
Agriculture
Year
2017
Sale Type
New
Manufacturer
Case IH
Row Spacings, In (mm)
7.5, 10, 12 (191, 254, 305)
Seeding Method
Min-Till / Conventional Till hoe
Seed Supply, Air Cart Or Integral Tank, Bu (L)
Air Cart
Working Width, Minimum, Ft-in (m)
60' (18.3)
Working Width, Maximum, Ft-in (m)
70' (21.3)
Transport Width, Minimum, Ft-in (m)
17' 8'' (5.4)
Transport Width, Maximum, Ft-in (m)
17' 8'' (5.4)
Number Of Furrows, Minimum
60
Number Of Furrows, Maximum
96
Basic Weight, Minimum, Lb (kg)
31,100 (14104)
Basic Weight, Maximum, Lb (kg)
36,500 (16516)
Variants Available
2
