OPTIONS TO MATCH CONDITION

The Case IH Tiger-Mate 200 can be enhanced with:

• Advanced Leveling System (ALS) harrows
• Advanced Conditioning System (ACS) harrows

These additions can be made with our without the optional Case IH Crumbler® attachment depending on soil conditions and desired outcome. Based on your soil environment and farming practices, the ideal combination of tools can be configured to:

• Properly distribute residue
• Size clods
• Firm the seed zone

CUT PATTERNS

• The first three rows of shanks take a full cut through the soil
• The fourth and fifth rows cut out the middles
• Soil, residue and chemicals are mixed and spread uniformly across the width of the unit
• Components are mixed throughout the tillage depth
• Results in even tracking and uniform sweep wear
  • Even loading on each side of the sweep prepares a level seedbed
    • Promotes uniform emergence

MAXXI-POINT™ SWEEP

The Maxxi-Point sweep features:

• A heavy-duty, extended-length nose
• A half-inch- wide wear point
  • Improves penetration to outperform competitive sweeps
• Heavy-duty construction from 6.5-mm, high-strength, Earth Metal^® alloy steel
  • Increases toughness
  • Promotes longer wear life

MAXXI-GRIP™ SWEEP

• A low crown for less groove
• A long nose for extra-long wear
• A curved edge for better cutting action
• Available in 7- and 9-in (178- and 299-mm) sweeps

UNIFORM DEPTH

Unlike look-alike models, the Tiger-Mate 200 uses a shank package that ensures the cultivator stays at a uniform depth.

• Critical to creating a level seedbed
• True 150 lbs (68 kg) of tip force
  • Provides consistent holding power in extreme conditions
  • Ensures penetration at higher speeds in hard ground
  • Maintains uniform depth and residue flow
• Standard 14-in (356 mm) trip height
  • Clears virtually every obstruction
• Compression springs
  • Maintain holding force throughout the shank life
• "Clamp-style" mounts with positive stops
  • Provide a level, uniform bed

TIGER-TINE HARROW

The Tiger-tine™ harrow uses a combination of split-the-middle indexed-tine placement, parallel linkage and three tine angle adjustments to achieve superior field performance.

• Indexed tines on four bars
  • Create smooth, level fields
  • Evenly distribute soil and residue
  • Break clods
  • Kill weeds
• Double tines on the first rank are evenly centered between sweeps
  • Knock down the ridge left by shanks
• Second, third and fourth ranks split the middle prior to ranks again
  • Level any remaining ridge
• Results in an effective, 20-in. (51-mm) tine spacing
  • Unparalleled performance
  • Handles heavy residue without bunching or allowing clumped residue to drag
• Parallel linkage and non-linked tine bars
  • Allows for independent movement and flexibility
  • Prevents skips and gouges when going over terraces and through draws
  • Keeps the unit level from front to back and side to side
  • Depth and level adjustments are eliminated for maximum productivity
• Two pins per arm adjust the tine angle and spring pressure (no tools needed)
  • 5 degrees – for aggressive leveling in heavy soils with minimal residue
  • 20 degrees – the standard setting for most soils and residue
  • 35 degrees – for extremely heavy residue

COIL TINE HARROW

• Three-bar design and 15-in. (38-cm) rank
  • Promotes excellent residue flow and leveling
• 16-in. (41-cm)-long, 7/16-in. (11.1-mm)-diameter double-coil tines with 1 1/2-in. (63.5-mm) effective spacing
• Tines rotate to prevent damage when backing up

SPIKE TOOTH HARROW

• Five-bar design and 10-in. (254-mm) rank
• Promotes excellent leveling and clod breakage
• 11-in. (279-mm)-long, 3/4-in. (19-mm)-square wide teeth with 1 1/2-in. (38-mm) effective spacing
