ID # 13228898

2014 Can-Am Commander™ Max DPS™ 1000

  • 2014 Can Am Commander™ Max DPS™ 1000
  • 2014 Can Am Commander™ Max DPS™ 1000
  • 2014 Can Am Commander™ Max DPS™ 1000
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Hqdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
Videos
Retail: $18,099 CAD
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Commander Max DPS

Lead the way with the most versatile four-seater rec-utility vehicle available.
Specifications
Model
Commander™ Max DPS™ 1000
Category Name
ATVs
Year
2014
Sale Type
New
Manufacturer
Can-Am
Color
Yellow
Engine
V-twin, SOHC, 8-valve (4 valves per cylinder)
Bore And Stroke
91 x 75 mm
Starting
Electric
Transmission
CVT, sub-transmission with high, low, park, neutral and reverse; standard engine braking
Suspension (Front)
Double A-arm with dive-control geometry, Motion Control shocks; 10 in. (25.4 cm) travel
Suspension (Rear)
Torsional Trailing arm Independent (TTI) with external sway bar, Motion Control shocks; 10 in. (25.4 cm) travel
Brakes (Front)
(2) 220 mm ventilated disc brakes with hydraulic twin-piston (32 mm) calipers
Brakes (Rear)
(2) 214 mm ventilated disc brake with hydraulic single-piston (32 mm) caliper
Tires (Front)
Maxxis Bighorn 2.0 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm)
Tires (Rear)
Maxxis Bighorn 2.0 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm)
Length
147.8 in. (375.3 cm)
Width
58.6 in. (148.9 cm)
Height
75.4 in. (191.6 cm)
Wheelbase
105.3 in. (267.3 cm)
Ground Clearance
11 in. (27.9 cm)
Fuel Capacity
10 gal. (37.8 l)
Towing Capacity
1,500 lbs. (680 kg)
Weight
1,562 lbs. (708 kg) dry
Displacement
976 cc
Fuel System
iTC™ with EFI and 54 mm throttle body, 2 Siemens VDO injectors
Cooling
Liquid
Drive System
Selectable 2WD / 4WD shaft driven with Visco-Lok QE auto-locking front differential
Brakes Rear
(2) 214 mm ventilated disc brake with hydraulic single-piston (32 mm) caliper
Brakes Front
(2) 220 mm ventilated disc brakes with hydraulic twin-piston (32 mm) calipers
Wheels
14 in. cast aluminum wheels with machined finish
Lighting
240W from (4) 60W projectors with tail lights / brake light
Suspension Front
Double A-arm with dive-control geometry, Motion Control shocks; 10 in. (25.4 cm) travel
Frame
Steel; 2 in. (5.1 cm) diameter, high-strength steel, ROPS-approved cage
Cargo Box Capacity Total
600 lbs. (272 kg)
Cargo Box Capacity Upper
400 lbs. (181 kg)
Cargo Box Capacity Lower
200 lbs. (91 kg)
Steering
Adjustable tilt
