It's mean, lean, cleaning machine. This gives a new meaning to joy ride. Take a ride while cleaning, grooming lawns...
Requires
Winch to lift accessory (1000 lb & more)
Rear ball hitch (2'').
Please verify measurements of vehicle to ensure proper fit and if optional extension kit for subframe is required.
If the measurement from front of bumper to the rear ball hitch is longer than 100" you will need the subframe extension kit #700455.
Will not fit if measurements are longer than 138''
Durability
Made of 16 gauge steel and other high performance components & design.
Performance
11 HP "Honda" GX340 with Cyclone air filter
Air filter specifically for dusty conditions with dual air filter.
Installation
No more wasted time! This beauty attaches within MINUTES on most major brands of UTVs.
The mounting system goes underneath the UTV and goes all the way to the rear to hook up on the tow hitch. It is adjustable for different lengths of UTVs. At the front it hooks up to the front axles with some chains. It's that simple and quick.
UTV must be equipped with a winch to lift broom.
Benefits
Controls at your fingertips.
All from the comfort of your seat:
Flip a switch to angle the broom to the left or right.
Comes Complete
Universal mounting hardware
Motor
Dust protector
Electric controls
Side markers
Side wheels support kit
Parking stand
Extendible Frame
4.75'' wide frame is adjustable to different lengths: from 67.50'' to 106.50''.
Easy Storage
Parking stand to facilitate storage.
Dolly Wheel
Dolly wheels frame supports the weight of the broom so there is no added weight to the vehicle.
Specifications
Lift
Uses vehicle's winch (not included).
Includes stopper (limit switch) to avoid damage to the vehicle when raising the unit.
Dimensions
Total Polypropylene Brush:
66'' x 24'' diameter
Stiff brush appropriate for any type of chore.
No steel wires to harm lawns or turfs.
Warranty
Semi-commercial Use : 1 year
Commercial, Professional or Rental Use: 90 days
Weight
1050 lbs approx.
Powder Coating
Black powder coat is baked on for a long rust free life.
1 Brush
Wafer style sections
Facilitate replacement. One section clips into the other.
2 Dust Protector
12''
Keeps dust directed toward the ground and helps reduce the risk of thrown debris.
3 Motor
11 HP "Honda" GX340 with Cyclone air filter
Air filter specifically for dusty conditions with dual air filter.
4 Pressure adjustment
Adjust pressure to adapt to a type of chore.
More pressure for pavement, less for turfs. This adjustment allows to compensate for brush wear of up to 50% wear before replacing brush.
5 Dolly Wheels
9" caster wheels for all terrain use
Wheels are located behind the unit allowing driver to sweep up close to buildings curves etc...
Dolly wheel frame supports the weight of the broom so there is no added weight to the vehicle.
6 Sleeves
Allows the installation of the side wheel kit.
Recommended for lawn dethatching. Allows the broom to float easily over the uneven terrain (see options section for more details).
7 Parking Stand
Protects bristles when stored.
8 Side Markers
Offers safer driving conditions for a more precise sweeping.
9 Rear View
Quick Hook up
Rear hicth: extendible frame hooks up to the rear ball hitch.
Chains with straps or brackets (brackets stay on permanently) attach to the front axles.
Dolly wheel frame supports the weight of the broom so there is no added weight to the vehicle.
