Overview



Mini Skid Steer Stump Grinder - S14

The S14 skid steer stump grinder is designed with simple operation in mind, with no required electrical connection. The direct flow hydraulic drive is designed to provide the best torque and RPM to the cutting head as no flow is diverted to a swing cylinder. The S14 mini tool carrier stump grinder features green carbide teeth which can be rotated three times, letting you grind stumps longer and faster on very low flow. The unique positioning of the rotor allows the operator an excellent view of the grinding action and the heavy duty fixed deflector safely directs the flow of debris. Cutting depth is up to 10" below ground. The S14’s size and the available mini skid steer mount makes it a great stump grinder for better access to tight areas and a nice addition to the rental offering on a mini skidsteer.
By a quick pull of two pins a standard size skidsteer plate can be put on as well.
  Features
Excavator Mount
Excavator Mount

This standard mounting plate is perfect for welding to your skid steer’s unique fitting.

Excavator Mount
Green Teeth

The concave shaped carbide tip provides aggressive brush mulching action by chipping the brush bit by bit. Part of the secret of their performance is always having a sharp edge to make grinding easier. Sharper edges result in aggressive cutting. These round carbide tipped teeth can be rotated up to 3 times to provide renewed cutting performance, giving you 3 times the wear by grinding 3 times longer.

Excavator Mount
More Teeth

The high number of teeth means that each tooth needs to do less work. Each of the Stump Blasters teeth only need to make a small cut, because the work is shared by more of our rugged teeth they last longer and usually only require 2 or 3 replacements at a time. The bolt-on designed teeth allow for straightforward replacement.

Excavator Mount
Hydraulic Motor

Skid steer mounted Stump Blasters run on hydraulic motors. For best results, match your equipments flow rate to one of our available hydraulic motor options.

Excavator Mount
More Clearance

The Stump Blaster’s carbide teeth extend a full 1-¼ inches from the rotor. This prevents chips and mulch from getting plugged. More chip clearing produces smoother operation and reduces heat build-up that can damage the rotor and cause premature tooth failure.

Excavator Mount
Rotor

The massive ¾" thick steel rotor provides the back bone for the Stump Blaster cutting system. It’s the anchor for the carbide tipped teeth. For smooth operation it’s important that the rotor remains solid, with no flexing. The rugged rotor also provides the Stump Blaster with the extra momentum needed when the grinding is tough, making sure the Stump Blaster can power through the hardest stumps.

Excavator Mount
Greaseable Pins

Our grease pins are zinc plated to prevent corrosion which will allow for smoother operation of the units joints over their lifetime.

  Stump Cutting Times

S250 Motor 24" Stump Grind Time
  PSI Case Drain 8 GPM 10 GPM 12 GPM 14 GPM 15 GPM

Gerotor

Hoses and Couplers
Included

50cc Displacement

 2,500 No 45 min 40 min 35 min 30 min N/A
3,000* No 45 min 40 min 35 min 30 min N/A
Rotor RPM 520 620 825 900 N/A
   * Motor will run at this PSI but excess pressure is dumping over relief

S450 Motor 24" Stump Grind Time
  PSI Case Drain 10 GPM 12 GPM 15 GPM 20 GPM 25 GPM

Gerotor

Hoses and Couplers
Included

125cc Displacement

 2,500 No N/A 50 min 45 min 35 min N/A
3,000 No N/A 45 min 40 min 30 min N/A
3,500* No N/A 45 min 40 min 30 min N/A
Rotor RPM N/A 375 475 520 N/A
   * Motor will run at this PSI but excess pressure is dumping over relief



Specifications
Model
S14
Category Name
Agriculture
Year
2018
Sale Type
New
Manufacturer
Bauma Light
Recommended HP Size
12-30
Maximum Carrier Size
Check GPM & PSI
Motor Type
Gerotor
Hydraulic GPM
Check Stump Cutting Size Chart
Rotor Size
18''
Number Of Teeth
12
Tooth Construction
Green
Cutting Wheel Speed
Depends on GPM
Cutting Height - Above Ground
No limit
Cutting Depth - Below Ground
6''
Maximum Cutting Depth - Per Pass
2''
Maximum Horizontal Cut
12''
Swing Arc
Self-feeding
Hub Torque
150 Ft.-Lbs.
Over Torque Protection
Relieve valve
Hitch
1'' pivot pins
No Of Remotes Required - Hydraulic
1
Unit Weight (Shipping) Lbs
394
