Baumalight LASER GUIDANCE

  • Baumalight LASER GUIDANCE
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

LASER GUIDANCE

It's time to level the playing field.

Rugged, reliable and accurate, the Latec LT-180 is an affordable, automatic true self-leveling single slope laser. Ideal for drainage work, the Latec LT-180 is the perfect partner for your Undertow to ensure exceptional leveling when plowing.

  Features

Automatic self-leveling in level and slope mode


Height of instrument alert (HI alert)

Long 2,000 foot (700m) operating diameter

Machine control compatible

635nm visible red beam

Optional recharge kit

Wide temperature range thermal compensation
  Specifications
  •  Range (Diameter): Up to 2,000 ft.* (700m)
  • Accuracy: ±10 arc seconds
  • Self-leveling Range: ±3°
  • Rotation Speed: 60, 300, 600, 750 RPM
  • Grade Range: -10% to 15%
  • Grade Increments: .01% from -2.5 to 2.5% .05% from 2.5 to 15%
  • Grade Accuracy: +/- .01 to 2.5% = .01% +/-2.5 to 15% = .08%
  • Laser Type: 635nm Visible, (Class 3a FDA) (Class 3R IEC)
  • Battery Life Alkaline: Approx. 60 hrs
  • Battery Life NiCad: Approx. 40 hrs
  • Operating Temp: -4?F to 122?F (-20?C to 50?C)



Specifications
Model
LASER GUIDANCE
Category Name
Agriculture
Year
2018
Sale Type
New
Manufacturer
Bauma Light
